nVent P19RP12UP - ProLine Rack Panel EIA Spacing 12U, 533x483x2.5mm, Light Gray, Mild Steel
nVent

P19RP12UP

UPC: 783510768201

Contact for Pricing

Overview

Enhance your network infrastructure with the nVent ProLine Rack Panel, SKU P19RP12UP. This robust 12U rack panel is engineered for superior performance and durability in demanding industrial and commercial environments. Constructed from high-quality mild steel with a professional light gray finish, it offers a reliable solution for organizing and securing your sensitive electronic equipment within standard 19-inch rack systems. The ProLine Rack Panel is designed with precision, featuring EIA standard spacing for its oblong mounting holes. This ensures seamless compatibility with a wide array of rack-mountable components, from servers and switches to patch panels and audio-visual equipment. Its substantial 533x483x2.5mm dimensions provide ample surface area for mounting, whether you are installing new devices or creating blanking spaces to optimize airflow and maintain a clean, professional aesthetic within your rack. Professionals choose nVent for their commitment to quality and innovation in enclosure and connectivity solutions. The ProLine series exemplifies this dedication, offering products that are not only functional but also built to last. This rack panel is an essential component for data centers, telecommunication facilities, broadcast studios, industrial control rooms, and any application requiring organized and secure equipment mounting. Key features and benefits of the nVent ProLine Rack Panel (P19RP12UP) include: * **Generous 12U Capacity:** Provides ample vertical space for mounting multiple devices or creating strategic blanking. * **Durable Mild Steel Construction:** Ensures long-term structural integrity and protection for mounted equipment. * **EIA Standard Spacing:** Facilitates easy and secure installation of standard 19-inch rack components. * **Optimized Airflow and Aesthetics:** Can be used as a blanking plate to improve cooling efficiency and maintain a tidy rack appearance. * **Professional Light Gray Finish:** Offers a clean, modern look that complements any rack environment. * **nVent Quality Assurance:** Manufactured by a trusted leader in electrical and electronic enclosure solutions. Installation is straightforward, with the panel mounting directly to rack angles. While the panel itself is designed for easy integration, please note that mounting hardware is sold separately. For optimal fastener selection, nVent recommends the ECNSM6 fastener package kit, ensuring a secure and compliant installation. Invest in the nVent ProLine Rack Panel (P19RP12UP) to elevate the organization, security, and efficiency of your critical equipment installations.
  • Available in aluminum or painted steel; steel is RAL 7035 textured light-gray polyester powder paint
  • Aluminum panels are 0.125-in. thick 5052-H32 alloy; steel panels are 12 gauge
  • All panels are flat with oblong holes positioned at EIA standard spacing (rack units)
  • Mounting hardware sold separately; recommend use of ECNSM6
  • Manufactured by nVent, a trusted name in industrial enclosure solutions.

Specifications

Application
Controls and Drives
Color
Light Gray
Color Code
RAL 7035
Finish
Powder Coated
Material
Mild Steel
Modification Services
Yes
Product Family
ProLine
Rack Angle Size
19 in.
Rack Units
12
Size
12Ux19.00 in
Thickness
12 ga
Thickness
2.66 mm
Type
Internal Mounting for ProLine Industrial Enclosures
Weight
12.24 lb
Package Dimensions (L x W x H)
21.5 IN x 21.25 IN x 1.25 IN
Package Dimensions (L x W x H)
54.61 cm x 53.975 cm x 3.175 cm
Package Weight (Imperial)
12.240 L
Package Weight (Metric)
5.552 kg
