Overview
- Not re-built from light industrial air conditioners
- Painted galvanized sheet metal cover for rugged factory and outdoor environments
- Corrosion resistant coating on ambient side components for Type 4X models
- Corrosion resistant coating on ambient and enclosure side components for Type 4X Offshore models
- Dust resistant coils for filterless operation in most environments
- Cleanable, reusable aluminum mesh filter protects coils for extremely dusty and dirty atmospheres
- Digital temperature control
- Narrow design to accommodate 12-in (300-mm) deep cabinets
- R134a, R513A or R407C earth-friendly Refrigerant
- Models for 115, 230 and 400/460 3-phase VAC power input
Specifications
Application | Hazardous Environments |
Btu Rating | 4,000 |
Color | Unpainted |
Color | Brushed |
Depth | 356 mm |
Depth | 14 in |
Finish | Brushed |
Frequency | 60 Hz |
Height | 711 mm |
Height | 28 IN |
Ip Rating | IP4X |
Material | Stainless Steel 316L |
Material | Stainless Steel 316 |
Material | SS316 |
Max Current | 9.4 A |
Nema Rating | Type 4X |
Nominal Capacity Btu/h | 4,000 Btu/h |
Nominal Capacity Watts | 1,172 W |
Nominal Voltage | 115 V |
Operating Temperature | -40-52 °C |
Operating Temperature | -40-125 |
Operating Temperature | -40-52 |
Product Family | SpectraCool |
Remote Access Control | No |
Series | SpectraCool Narrow Hazardous Location |
Series | SpectraCool Narrow Hazardous Location AC |
Size | 4000 BTU |
Thickness | 1.27 mm |
Thickness | 18 ga |
Thickness | 51.40mm (2.024") |
Type | Air Conditioners |
Voltage AC | 100-120 V |
Voltage Rating | 115 V |
Voltage Rating | 100 - 120 VAC |
Weight | 38 kg |
Weight | 87 lb |
Width | 292 mm |
Width | 11.5 in |
Package Dimensions (L x W x H) | 18 IN x 13.5 IN x 30.25 IN |
Package Dimensions (L x W x H) | 45.72 cm x 34.29 cm x 76.835 cm |
Package Weight (Imperial) | 87.000 L |
Package Weight (Metric) | 39.463 kg |
How to Install the NHZ280416G400 Air Conditioner
This guide provides step-by-step instructions for the installation and initial setup of the NHZ280416G400 air conditioner in hazardous locations.
Estimated time: 1h
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors, Mounting gasket kit
- Inspect the air conditioner
Check the air conditioner for any visible damage from shipping. Ensure it is in an upright position for at least five minutes before proceeding.
- Mount the air conditioner
Using the mounting gasket kit, secure the air conditioner to the enclosure while ensuring the gasket is not damaged. Maintain a six-inch clearance on at least one side and twenty inches in front for cover removal.
- Wire the air conditioner
Refer to the nameplate for electrical requirements and connect the air conditioner to a properly grounded power supply using copper conductors. Ensure the circuit is fused with a slow blow or HACR circuit breaker.
- Adjust the controller settings
Set the desired cabinet temperature on the controller. Refer to the manual for specific instructions on displaying and changing program settings.
- Test the air conditioner
After wiring, energize the unit and verify that the evaporator blower starts running. Allow the compressor to operate for five to ten minutes and check for proper functionality.
