nVent MPR1000 - Mounting Plate Reinforcement Profiles, MPR, 35x882x21mm, Galvanized, Mild Steel
nVent

MPR1000

UPC: 783510514044

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent MPR1000 Mounting Plate Reinforcement Profiles (SKU: MPR1000) are engineered to reinforce standard mounting plates in industrial enclosures subjected to heavy equipment loads. Each pack includes two 35x882x21mm profiles made from 2mm galvanized mild steel, providing corrosion resistance and durability in demanding environments. These profiles prevent sagging and deformation of mounting plates, ensuring long-term reliability for control panels and electrical systems. Designed for vibration dampening and stabilization, the MPR1000 significantly reduces operational shocks and vibrations that can damage sensitive electronic components. Installation requires no additional drilling, enabling quick and efficient setup to minimize downtime. For optimal performance, nVent recommends securing the mounting plate directly to the reinforcement profile. Compatible with enclosure widths of 1000mm, these profiles are ideal for manufacturing, automation, power distribution, and telecommunications applications where robust electrical enclosures are essential. The galvanized steel construction ensures long-lasting performance in harsh industrial conditions.
  • Description: Reinforcing a mounting plate (MP) when heavily equipped. For dampening of vibrations and stabilization. Easy mounting without drilling. In order to achieve maximum damping, fixing of the mounting plate to the profile is advised.
  • Material: 2 mm galvanized steel.
  • Pack quantity: 2 profiles with mounting accessories.
  • Benefit: customers can mount heavy components onto the mounting plate while dampening down any vibrations
  • Comment: highly recommended to mount the reinforcement brackets, MPE or MPEF in combination with the profiles

Specifications

Application
Factory Automation and Process Control; Controls and Drives
Color
Unpainted
Consist of
Mounting Plate Reinforcement Profiles; Mounting Components and Instruction Manual
Construction
14 gauge
Depth
0.83 in
Depth
21 mm
Enclosure Material
Mild Steel
Finish
Galvanized
Height
1.38 in
Height
35 mm
Material
Mild Steel
Package Quantity
2
Product Family
Free-Standing
Size
1.38 x 34.72 x 0.83 inch
Thickness
2 mm
Thickness
14 ga
Type
IEC Enclosure Accessories
Type
Mounting
Weight
5.6 lb
Weight
2.5 kg
Width
1,000 mm
Width
34.72 in
Width
39.37 in
Works With
IEC
Package Weight (Imperial)
5.600 L
Package Weight (Metric)
2.540 kg
