nVent MPG12R5 - Console, 985x1200x400, Compact enclosure, with MP, mild steel, IP55
nVent

MPG12R5

UPC: 783510512521

Contact for Pricing

Overview

The nVent MPG12R5 is a robust, mild steel compact console designed for demanding industrial environments. Measuring 985x1200x400 mm, this enclosure provides ample space for Human Machine Interface (HMI) equipment and control systems. Engineered for reliability and ease of use, the MPG series offers a practical solution for housing sensitive electronics. This console boasts a double-bit 3 mm lock system for both the top panel and the base, ensuring secure access. The bottom opening facilitates straightforward cable entry, with bottom plates for cable glanding supplied as standard. Integrated M8 threaded studs on the body, door, top panel, and rear panel provide convenient earthing points, crucial for electrical safety and equipment protection. The standard finish is a durable RAL 7035 structured powder coating, offering excellent resistance to wear and tear. For double-door configurations, the MPG console achieves an IP 55 protection rating, suitable for environments where dust and water ingress are less critical but still require significant protection, alongside TYPE 12, 13, and IK 10 ratings.
  • Robust mild steel construction for industrial environments
  • Dimensions: 985x1200x400 mm, providing ample space for HMI and control systems
  • IP 55 protection rating (double door configuration)
  • Double-bit 3 mm lock system for enhanced security
  • Integrated M8 threaded studs for convenient earthing
  • Cable inlet: Bottom opening for cable access. Bottom plates for cable glanding supplied as standard.
  • Earthing: M8 threaded studs on body, door, top panel and rear panel.
  • Finish: RAL 7035 structured powder coating.
  • Protection: Single door: IP 66, TYPE 4, 12, 13, IK 10. Double door: IP 55, TYPE 12, 13, IK 10.
  • Delivery: Mounting plate and suitable nuts and washers for earthing. The console is delivered on a wooden pallet.

Specifications

Body Thickness
0.06 in
Body Thickness
16 ga
Color
RAL 7035
Color
Gray
Color
Grey
Color Code
RAL 7035
Depth
400 mm
Depth
15.75 in
Door Thickness
0.06 in
Door Thickness
14 ga
Finish
Powder Coated
Height
985 mm
Height
38.78 in
Ip Rating
IP55/IP66
Material
Mild Steel
Max Mounting Depth
11.1 in
Max Mounting Depth
13.11 in
Nema Rating
Type 4/12/13
Panel Size
72.00 x 72.00 in
Panel Size
31.1 x 43.27 in
Protection Rating
IP55
Series
MPG
Size
985x1200x400 mm
Type
HMI Enclosure Systems
Weight
196.25 lb
Weight
32 lbs./100ft
Width
1,200 mm
Width
47.24 in
Package Dimensions (L x W x H)
47.62 IN x 39.15 IN x 47.87 IN
Package Dimensions (L x W x H)
120.9548 cm x 99.441 cm x 121.5898 cm
Package Weight (Imperial)
236.400 L
Package Weight (Metric)
107.231 kg
