Overview
- Seams continuously welded and ground smooth
- External formed body flange channels away liquids
- Large perimeter body opening
- Mounting holes in back of body for direct mounting or optional external mounting brackets
- Bonding provision on cover and body
- Metalized non-woven fabric EMI/RFI material covering UL94HP-rated urethane foam gasket
- Plated interior surfaces for gasket contact areas and conduit entries
- Hardware kit includes panel mounting screws, grounding hardware and sealing washers for wall-mounting holes
- Installation instructions
- Shielding effectiveness greater than 50 dB at 1 GHz
Specifications
Application | Controls and Drives |
Color | Gray;LtGray |
Color | Light Gray |
Color Code | RAL 7035 |
Conductive Steel Panel | LP1515G |
Depth | 4.72 |
Depth | 120 |
Depth | 120 mm |
Finish | Powder Coated |
Height | 150 mm |
Height | 5.91 in |
IP Rating | IP54 |
Material | Steel |
Material | Mild Steel |
Modification Services | Yes |
Mounting | 5.20 x 3.35 in |
Mounting | Wall Mounting Brackets Available |
NEMA Rating | 1 |
NEMA Rating | 1 Indoor, electrical protection |
Panel Size | 5.16 x 5.16 in |
Panel Size | 131 x 131 mm |
Product Family | InLine |
Protection Rating | NEMA Type 1 |
Size | 150x150x120mm |
Steel Panel | LP1515 |
Thickness | 1.5 mm |
Thickness | 16 ga |
Thickness | 51.40mm (2.024") |
Type | Mild Steel Wall Mounted Industrial Enclosures |
Type Number | Type 12 |
Weight | 3.8 lb |
Width | 150 mm |
Width | 5.91 in |
Package Dimensions (L x W x H) | 6.5 IN x 6.5 IN x 5.7 IN |
Package Dimensions (L x W x H) | 16.51 cm x 16.51 cm x 14.478 cm |
Package Weight (Imperial) | 3.800 L |
Package Weight (Metric) | 1.724 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the LHC151512EMC Controller
This guide provides step-by-step instructions for installing and configuring the LHC151512EMC Controller on a DIN rail.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the LHC151512EMC controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the power supply
Using terminal connectors, connect the power supply wires to the designated input terminals on the controller. Verify that the connections are tight to prevent any loose wiring.
- Wire the input/output connections
Connect the input and output devices to the corresponding terminals on the controller. Use a multimeter to check for proper voltage levels after connections are made.
- Configure the controller settings
Power on the controller and access the configuration menu. Set the desired parameters according to your application requirements.
- Calibrate the controller
Follow the calibration procedure outlined in the user manual to ensure accurate readings and performance. Make adjustments as necessary.
