Contact for Pricing
Overview
- 24-inch black 16 AWG ganging cable for PaneLite LED and Fluorescent lights
- Connects up to five lights to a single power source, reducing wiring complexity
- Direct plug-in design for secure connection to either end of PaneLite lights
- Compatible with both LED and Fluorescent PaneLite models
- Eliminates need for individual power runs, saving installation time and cost
Specifications
Accessory Type | Lighting |
Application | Power Distribution; Controls and Drives |
Color | Black |
Connection Type | Plug-in |
Finish | Smooth Matte |
Length | 24 in. |
Material | Copper |
Material | PVC (16 AWG) |
Modification Services | No |
Product Family | PaneLite |
Series | PaneLite |
Size | 24 inch |
Size | 24 in. |
Thickness | 1.3 mm |
Type | Electrical Accessories |
Weight | 0.24 lb |
Package Dimensions (L x W x H) | 11 IN x 9.25 IN x 0.5 IN |
Package Dimensions (L x W x H) | 27.94 cm x 23.495 cm x 1.27 cm |
Package Weight (Imperial) | 0.240 L |
Package Weight (Metric) | 0.109 kg |
How to Install the Light Fixture Cabling
This guide provides step-by-step instructions for installing and wiring light fixtures safely and effectively.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Wire connectors
- Mount the light fixture
Secure the light fixture to the designated mounting surface using the provided mounting screws. Ensure it is level and firmly attached.
- Connect the wiring
Strip the ends of the wires and connect them to the corresponding terminals on the light fixture. Use wire connectors to secure the connections.
- Verify the connections
Use a multimeter to check the voltage at the fixture terminals to ensure proper electrical connection before powering on the light.
