Contact for Pricing
Overview
- 5W DC LED light kit with 400 lumens output
- Operates on 20-60 VDC power supply
- Integrated IR motion sensor for hands-free activation
- Magnetic or mechanical mounting options for UL Type 4X compliance
- Pre-assembled 78.7-inch (2000 mm) cable whip for easy installation
- Operating temperature -22 F to 140 F (-30 C to 60 C)
- Life expectancy of 60,000 hours at 68 F (20 C) under specifications
- Protection Class II (double insulated)
Specifications
Accessory Type | Lighting |
Activation | IR Motion Sensor |
Application | Power Distribution; Controls and Drives |
Color | Light Gray |
Finish | Smooth Matte |
Ip Rating | Type 4X |
Material | Plastic |
Modification Services | No |
Mounting Style | Magnetic |
Mounting Type | Magnetic Mounting / Mechanical Fastening |
Nema Rating | Type 4X |
Power Source | DC |
Size | 1.54x1.26x13.82 in |
Size | 1.34x1.26x13.82 |
Type | Electrical Accessories |
Voltage AC | 20 VDC-60 VDC V |
Voltage Rating | 20-60 VDC |
Weight | 140 g |
Package Dimensions (L x W x H) | 14.7 IN x 1.8 IN x 1.7 IN |
Package Dimensions (L x W x H) | 37.338 cm x 4.572 cm x 4.318 cm |
Package Weight (Imperial) | 0.500 L |
Package Weight (Metric) | 0.227 kg |
How to Install the LEDD2M35 Lighting Fixture
This guide provides step-by-step instructions for installing and configuring the LEDD2M35 lighting fixture safely and effectively.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Disconnect power supply
Ensure all power supplies to the enclosure are disconnected to avoid electric shock and equipment damage.
- Mount the fixture
Secure the LEDD2M35 fixture to the designated mounting surface using the provided mounting screws. Ensure it is level and firmly attached.
- Connect wiring
Connect the fixture to a power supply that matches the voltage and frequency specified on the product label. Ensure all wiring complies with applicable national and local electrical codes.
- Ground the fixture
Properly ground the lighting fixture to prevent electrical hazards.
- Test the fixture
Activate the test run by disconnecting and then reconnecting the power supply. The lamp should flash twice and then switch off.
- Verify operation
Reactivate the motion detector; the lamp should turn on for 5 seconds and then switch off, indicating it is ready for operation.
