Contact for Pricing
Overview
- Includes gasket and mounting hardware.
- Purchase Front Plate separately
- Light gray (RAL 7035) textured polyester powder paint finish
- Frame caps conceal mounting screws for a clean appearance
- 166x160mm window size with 136x109mm HMI cutout
Specifications
Accepts Front Plate | LFP1616 |
Application | Controls and Drives |
Color | Light Gray |
Color Code | RAL 7035 |
Depth | 17 mm |
Depth | 0.67 |
Depth | 17 |
Finish | Powder Coated |
Height | 6.54 |
Height | 166 |
Height | 166 mm |
Material | Zinc |
Material | Steel |
Modification Services | Yes |
Mounting Type | Frame with concealed mounting screws |
Product Family | InLine |
Series | InLine HMI |
Size | fits 166x160mm |
Size | 166x160mm |
Thickness | 0.03 in |
Thickness | 0.8 mm |
Type | HMI Enclosure Systems |
Weight | 1.4 lb |
Width | 6.3 |
Width | 160 |
Width | 160 mm |
Window Size | 136 x 109 mm |
Window Size | 5.35 x 4.30 in |
Package Dimensions (L x W x H) | 9.5 IN x 9.5 IN x 1 IN |
Package Dimensions (L x W x H) | 24.13 cm x 24.13 cm x 2.54 cm |
Package Weight (Imperial) | 1.400 L |
Package Weight (Metric) | 0.635 kg |
LWF1616
OI Window Kit, Fixed, Bulletin C3 (INLINE Operator Interface Enclosures), Size/Dims: fits 166x160mm, Material/Finish: Zinc cast
How to Install the LBF1616 Controller
This guide provides step-by-step instructions for installing and configuring the LBF1616 Controller on a DIN rail.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Verify dimensions and clearances
Check the dimensions and clearances for the installation site to ensure proper fit before proceeding with installation.
- Mount the controller
Secure the LBF1616 Controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect wiring
Use terminal connectors to connect the power and signal wires to the appropriate terminals on the controller. Ensure all connections are secure and insulated.
- Configure the controller
Power on the controller and use the interface to set the desired parameters according to your application requirements.
- Calibrate the controller
Perform calibration by following the manufacturer's instructions to ensure accurate readings and functionality.
