Contact for Pricing
Overview
- Material: Body: 1.5 mm. Door: 2 mm. AISI 304L pre-grained stainless steel. Mounting plate: 2 mm galvanized steel.
- Body: Monoblock body, folded and seam welded. The top of the body is equipped with a sloping roof at an angle of 30° toward the front, ending with a 30 mm overhang to avoid any draining liquids from dripping onto the gasket and the door.
- Door: Folded with a sloping angle of 8° on all sides. Surface mounted with 120° opening. Concealed zinc plated steel hinges with captive pin. Can be mounted to give left- or right-hand opening (machining is not required).
- Internal hinge: The door hinge is specially designed to be concealed inside the enclosure once the door is closed to avoid dirt from accumulating, making the enclosure easy to clean.
- Gasket: A one piece removable blue silicone gasket with molded corners ensures proper sealing, and makes removing and replacing it faster and easier for cleaning and replacement operations. The silicone is FDA 21 CFR 177.2600 compliant.
- Lock: HD lock made of stainless steel AISI 316L with blue silicone gasket, the lock conforms with norm DIN EN 1672-2:2009.
- Mounting plate: Fixed onto M8 studs welded on the rear of the enclosure. All sides from 800 mm and above are strengthened by folded edges. The mounting plate is marked vertically at 10 mm intervals for easy horizontal positioning of equipment.
- Cable access: No gland openings as standard to avoid hygiene risks.
- Protection: Corresponds with IP 66/69, TYPE 4X, 12, 13, IK08.
- Finish: 400 Pre-grained stainless steel, polished to Ra < 0.8 µm.
Specifications
Application | Hygienic Environments |
Degree of Slope | 30 ° |
Depth | 300 mm |
Depth | 11.81 in |
Finish | Brushed |
Height | 44 IN |
Height | 56.1 in |
Ip Rating | IP66/IP69 |
Material | Stainless Steel 304 |
Mounting Type | Wall mounted |
Nema Rating | Type 4X |
Panel Size | 72.00 x 72.00 in |
Panel Size | 49.21 x 29.53 in |
Protection Rating | IP66 |
Series | HDW |
Size | 1425x810x300 mm |
Thickness | 0.06 IN |
Thickness | 51.40mm (2.024") |
Type | Stainless Steel Wall Mounted Industrial Enclosures |
Width | 31.89 in |
Width | 810 mm |
Package Dimensions (L x W x H) | 56.48 IN x 32.26 IN x 32.51 IN |
Package Dimensions (L x W x H) | 143.4592 cm x 81.9404 cm x 82.5754 cm |
Package Weight (Imperial) | 191.300 L |
Package Weight (Metric) | 86.774 kg |
