Overview
- Heavy-wall 3.5-in. structural tube welded to a 12 x 12 x 3/8-in.-thick baseplate
- Provides a "rough-in" point and pull box for power and network field wiring
- Includes internal CAT5 coupler and finger-safe power terminals
- Two conduit knock-outs can be opened to either 1/2 in. or 3/4 in.
- Fully gasketed 16 gauge cover panel on junction box can be used for additional conduit attachment
- Tough, molded ABS junction box is contoured to fit the post and is fluted into the post to protect cables
- Tough, molded ABS junction box is contoured to fit the post and is fluted into the post to protect cables
Specifications
Application | Controls and Drives |
Color | Light Gray |
Color | Gray |
Color | Unpainted |
Color Code | RAL 7035 |
Depth | 302 mm |
Depth | 11.9 |
Depth | 302 |
Finish | Brushed |
Finish | Powder Coated |
Height | 1,880 mm |
Height | 74 |
Height | 1,880 |
Material | Steel |
Material | Stainless Steel 304 |
Modification Services | Yes |
Mounting Type | Floor-Mount |
NEMA Rating | 12 Indoor, dust-resistant |
Product Family | Syspend |
Protection Rating | NEMA Type 12 |
Size | 12x12x74 |
Size | 11.90x11.9x74 in |
Type | Vertical Motion Arms |
Weight | 29.48 kg |
Weight | 69 lb |
Width | 302 mm |
Width | 11.9 |
Width | 302 |
Package Dimensions (L x W x H) | 76 IN x 16 IN x 16 IN |
Package Dimensions (L x W x H) | 193.04 cm x 40.64 cm x 40.64 cm |
Package Weight (Imperial) | 69.000 L |
Package Weight (Metric) | 31.298 kg |
CCS6BBLG
Base Bracket, Pendant Arm, Bulletin CS4 (COMPACT® Suspension System - COMPACT Pendant Arm, Series 4), Size/Dims: fits 60x60mm, Material: Steel, Finish: Lt GrayCCS14BBLG
Base Bracket, Pendant Arm, Bulletin CS4 (COMPACT® Suspension System - COMPACT Pendant Arm, Series 4), Size/Dims: fits 80x140mm, Material: Steel, Finish: Lt Gray
How to Install the VL-Motion Arm
This guide provides step-by-step instructions for installing and adjusting the VL-Motion Arm, ensuring proper functionality and safety.
Estimated time: 1h
Tools needed:
Screwdriver, 1/8 inch Allen wrench, Spanner wrench
Supplies needed:
Bronze bushing, Flange axle, Mounting screws
- Install the mounting end
Remove the access cap and pass the Flange Axle through the plastic bushing and the arm. Install the bronze bushing between the arm and the mount, then screw the Flange Axle into the mount.
- Adjust the release cable
Adjust the release cable by turning the black cable adjuster screw until the free-play in the release handle is approximately 3/8 in. (9.5 mm). Ensure that the cable is not too tight or too loose.
- Adjust the swivel friction
Loosen the inner set screw on the arm end using a 1/8 inch Allen wrench. Turn the Flange Axle with the spanner wrench to achieve the desired swivel friction, then re-tighten the set screws to 30 in-lbs (3.4 N-M).
- Adjust the counterbalance force
Lower the arm and insert a #2 Phillips screwdriver into the valve actuator hole. Pump the screwdriver gently to release gas from the spring until the desired counterbalance force is achieved. Always wear safety glasses during this adjustment.
