Overview
- Description: Full height swing frame for 19” components allowing left and right hand opening with grip over the full height. Can be used in steel, combinable and compact enclosures. Hinges designed to give extra build-in depth. Adjustable top hinge for sq
- Maximum load: 1800 N, supplied with a self-positioning device.
- Lock: Double-bit 3 mm espagnolette (other lock options possible).
- Material: 19" vertical profiles 2 mm zinc plated steel. Frame: vertical profiles 2 mm and horizontal profiles 3 mm.
- Finish: RAL 7035 structured powder coating.
- Pack quantity: 1 swing frame with hinges.
- Mounting requirements: ESFS for 800 mm, 1000 mm wide steel, combinable enclosures. Add ESFB for mounting in a steel, combinable enclosure.
- Mounting requirements: ESFS for 800mm (31), 1000mm (39) wide steel, combinable enclosures; add ESFB for mounting in a steel, combinable enclosure
- Designed for combinable and compact enclosures
- Manufactured by nVent, a leader in electrical and thermal management
Specifications
Application | Controls and Drives; Factory Automation and Process Control |
Color | Unpainted |
Color | RAL 7035 |
Consist Of | Swing Frame Side Mounted; Mounting Components and Instruction Manual |
Construction | 11 gauge |
Depth | 3.15 in |
Depth | 80 mm |
Enclosure Material | Mild Steel |
Finish | Zinc Plated |
Height | 78.74 in |
Height | 1,867 mm |
Height | 2,000 mm |
Material | Mild Steel |
Material | Zinc-plated mild steel |
Mounting Type | Side-mounted swing frame |
Package Quantity | 1 |
Product Family | Free-Standing |
Rack Units | 40 U |
Series | ESFS |
Size | 73.5 x 27.32 x 3.15 inch |
Size | 1867x694x80mm |
Thickness | 3 mm |
Thickness | 11 ga |
Type | Mounting |
Type | IEC Enclosure Accessories |
Weight | 57.54 lb |
Weight | 26.1 kg |
Width | 694 mm |
Width | 27.32 in |
Works With | IEC |
Package Weight (Imperial) | 57.500 L |
Package Weight (Metric) | 26.082 kg |
