Overview
- Description: Full height swing frame for 19” components allowing left and right hand opening with grip over the full height. Can be used in steel, combinable and compact enclosures. Hinges designed to give extra build-in depth. Adjustable top hinge for sq
- Maximum load: 1800 N, supplied with a self-positioning device.
- Lock: Double-bit 3 mm espagnolette (other lock options possible).
- Material: 19" vertical profiles 2 mm zinc plated steel. Frame: vertical profiles 2 mm and horizontal profiles 3 mm.
- Finish: RAL 7035 structured powder coating.
- Pack quantity: 1 swing frame with 180° hinges.
- Mounting requirements: ESFM for 800 mm and 1000 mm wide steel, combinable enclosures. Add ESFB for mounting in a steel, combinable enclosure.
- Mounting requirements: ESFM for 800mm (31) and 1000mm (39) wide steel, combinable enclosures; add ESFB for mounting in a steel, combinable enclosure
Specifications
Application | Controls and Drives; Factory Automation and Process Control |
Color | Unpainted |
Consist Of | Swing Frame Middle Mounted; Mounting Components and Instruction Manual |
Construction | 11 gauge |
Depth | 3.15 in |
Depth | 80 mm |
Enclosure Material | Mild Steel |
Finish | Zinc Plated |
Height | 78.74 in |
Height | 2,000 mm |
Height | 1,867 mm |
Material | Mild Steel |
Package Quantity | 1 |
Product Family | Free-Standing |
Rack Units | 40 U |
Size | 73.5 x 27.32 x 3.15 inch |
Thickness | 3 mm |
Thickness | 11 ga |
Type | IEC Enclosure Accessories |
Type | Mounting |
Weight | 60.85 lb |
Weight | 27.6 kg |
Width | 694 mm |
Width | 27.32 in |
Works With | IEC |
Package Weight (Imperial) | 60.800 L |
Package Weight (Metric) | 27.579 kg |
