Contact for Pricing
Overview
- Maintains UL/NEMA Type 12 if properly installed in an nVent HOFFMAN enclosure
- UL/CSA Type 12 rating
- Removable cable egress and entry plate
- ANSI 61 gray polyester powder paint finish
- Easy installation with included hardware kit
Specifications
Accessory Type | Shelves, Keyboard Trays and Gland Plates |
Application | Controls and Drives |
Color | Gray |
Color Code | ANSI 61 |
Finish | Powder Coated |
Material | Steel |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Mounting Type | Tool-free with wing nuts |
Mounting Type | Wing Nuts |
Nema Rating | Type 12 |
Size | 9.94 inches (252 mm) length |
Size | 9.00x5.00 |
Size | fits 9.00x5.00 in |
Thickness | 51.40mm (2.024") |
Thickness | 1.52 mm |
Thickness | 16 ga |
Type | External Mounting for Industrial Enclosures |
Weight | 1.6 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 10.7 IN x 7.2 IN x 2.1 IN |
Package Dimensions (L x W x H) | 27.178 cm x 18.288 cm x 5.334 cm |
Package Weight (Imperial) | 1.600 L |
Package Weight (Metric) | 0.726 kg |
How to Install the Gland Plate
Step-by-step guide for installing the gland plate on a box to maintain UL/CSA Type 12 compliance.
Estimated time: 15m
Tools needed:
Screwdriver
Supplies needed:
Wing nuts, Support brackets
- Make the cut-out
Cut a hole in the box as specified in the documentation. The cut-out can be positioned on any side of the box.
- Install the gland plate
Slip the support brackets under the back side of the cut-out, push the gland plate down over the cut-out, and slide the bracket under the front edge of the cut-out.
- Tighten the wing nuts
Secure the gland plate by tightening the wing nuts to ensure it is firmly attached and maintains the necessary compliance.
