Overview
- Description: Horizontal profiles with 25 mm hole pattern. Fits directly onto the door frame. For easy mounting of light equipment by using CNT05 screws, hole pattern of 4.5 mm and 6.5 mm in diameter.
- Material: 2 mm zinc plated steel.
- Pack quantity: 20 bars with mounting accessories.
- Benefit: customers can install accessories, electrical components and cables exactly where they desire
- Comment: the mounting profiles can be used to reinforce the enclosure's door when exposed to heavy loads
Specifications
Application | Factory Automation and Process Control; Controls and Drives |
Color | Unpainted |
Color | Zinc Plated |
Consist of | Door Frame Mounting Profiles; Mounting Components and Instruction Manual |
Construction | 14 gauge |
Depth | 14 mm |
Depth | 0.56 in |
Enclosure Material | Mild Steel |
Finish | Zinc Plated |
Height | 24 mm |
Height | 0.96 in |
Material | Mild Steel, Zinc Plated |
Material | Mild Steel |
Mounting Type | Door frame mounting |
Package Quantity | 20 |
Product Family | Free-Standing |
Series | DCP |
Size | 24x992x14mm |
Size | 0.96 x 39.06 x 0.56 inch |
Thickness | 2 mm |
Thickness | 14 ga |
Type | Doors |
Type | IEC Enclosure Accessories |
Weight | 23.4 lb |
Weight | 10.6 kg |
Width | 992 mm |
Width | 39.06 in |
Works With | IEC |
Package Weight (Imperial) | 23.400 L |
Package Weight (Metric) | 10.614 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
Frequently Asked Questions
What is the material of the nVent DCP1002 mounting profile?
The nVent DCP1002 mounting profile is made from 2mm thick zinc-plated mild steel.
What is the hole pattern size and spacing on the DCP1002?
The DCP1002 features a 25mm hole pattern with individual holes of 4.5mm and 6.5mm in diameter.
What type of screws are recommended for mounting accessories?
The DCP1002 is designed for easy mounting of light equipment using CNT05 screws.
What are the dimensions of the nVent DCP1002?
The nVent DCP1002 measures 24mm x 992mm x 14mm.
Can the DCP1002 be used on larger enclosure doors?
Yes, for larger doors, two DCP profiles are recommended for adequate support.
