nVent CSD243010SS6 - Concept Wallmount 1/4-Turn Latch Type 4X, 24x30x10, Brushed, Stainless 316
nVent

CSD243010SS6

UPC: 783510128982

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent Concept Wallmount Enclosure, SKU CSD243010SS6, is engineered for demanding industrial environments where superior protection against corrosion, water, and dust is paramount. Constructed from robust 316 stainless steel with a brushed finish, this enclosure offers exceptional durability and resistance to harsh chemicals and environmental factors, making it an ideal choice for both indoor and outdoor applications. Its Type 4X and IP66 ratings ensure a high level of protection, safeguarding sensitive electrical and electronic components from ingress. The Concept Series is renowned for its streamlined styling and aesthetic appeal, featuring a clean, modern design that complements any facility. The flush quarter-turn latches provide secure and reliable closure, while also contributing to the enclosure's sleek profile. This thoughtful design not only enhances security but also simplifies access for maintenance and operational tasks. Key features of the nVent CSD243010SS6 include: * **Premium Material:** Fabricated from 316 stainless steel, offering superior corrosion resistance compared to standard stainless steel grades, particularly in saline or chemically aggressive atmospheres. * **Robust Protection:** Certified NEMA Type 4X and IP66, providing a high degree of protection against water jets, dust, and corrosive substances. * **Generous Size:** The 24x30x10 inch dimensions offer ample space for mounting various electrical components, control systems, and instrumentation. * **Secure Latching:** Features flush quarter-turn latches for easy yet secure access and a clean exterior appearance. * **Wall Mount Design:** Optimized for straightforward wall mounting, facilitating efficient installation and space utilization. * **Attractive Finish:** The brushed finish provides a professional and aesthetically pleasing look, suitable for visible installations. This enclosure is a critical component in industries such as chemical processing, food and beverage, water treatment, pharmaceuticals, and any sector where equipment must be protected from corrosive elements and washdown procedures. The choice of 316 stainless steel is particularly important for applications involving exposure to chlorides, acids, and other aggressive chemicals. nVent's commitment to quality and innovation is evident in the robust construction and thoughtful design of the Concept Series, ensuring long-term reliability and performance. Professionals select nVent enclosures for their proven track record in providing secure, durable, and compliant solutions for critical infrastructure. The CSD243010SS6 represents a reliable investment in protecting valuable equipment and ensuring operational continuity in challenging conditions.
  • Minimum-width body flange provides maximum body opening
  • External formed 90-degree body flange
  • Panel mounting studs fit optional Concept panels and other accessories
  • Mounting holes in back of body for direct mounting or for optional external mounting brackets
  • Type 316 stainless steel hidden hinges promote clean aesthetic appearance
  • Corner formed doors are interchangeable and easily removed by pulling clip-style hinge pins
  • Provision on door (except when B = 12 inch (305mm)) for thermoplastic data pocket
  • Provision on door (except when B = 12 inch (305mm)) for optional doorstop kit
  • Quarter-turn latches furnished with flush slotted insert
  • Seamless foam-in-place gasket

Specifications

Application
Controls and Drives;Corrosive Environments
Body Thickness
1.59 mm
Body Thickness
16 ga
Color
Unpainted
Conductive Panel
CP3024G
Depth
10 IN
Depth
254 mm
Door Thickness
1.98 mm
Door Thickness
14 ga
Finish
Brushed #4
Height
610 mm
Height
24 in
IP Rating
IP66
Latch Quantity
2
Latch Type
Quarter-turn
Material
Stainless Steel;Stainless Steel 316L
Material
Stainless Steel 316L
Modification Services
Yes
Mounting
22.50 x 28.50 in
Mounting
Wall Mounting Brackets Available
NEMA Rating
4X Watertight, corrosion-resistant
NEMA Rating
4X
Panel
CP3024
Panel Size
716 x 564 mm
Panel Size
28.20 x 22.20 in
Product Family
Concept
Protection Rating
NEMA Type 3R
Protection Rating
NEMA Type 12
Size
24.00x30.00x10.00 in
Style
Quarter-turn
Type
Stainless Steel Wall Mounted Industrial Enclosures
Type Number
Type 3R
Weight
53 lb
Width
762 mm
Width
30 IN
Package Dimensions (L x W x H)
31 IN x 28.75 IN x 12.25 IN
Package Dimensions (L x W x H)
78.74 cm x 73.025 cm x 31.115 cm
Package Weight (Imperial)
53.000 L
Package Weight (Metric)
24.041 kg
Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum

14A0705

Panel 6.9 x 4.9 - Fits Encl. 8 x 6 - Alum
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.

BX4

Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black

LH38

Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
EP-RJG-M20-BL-A

1SNG618003R0000

EP-RJG-M20-BL-A
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey

LN43DA

1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey

LT20D-NEW

1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
Escutcheon black type B for Sircover 125-630A

44095015

Escutcheon black type B for Sircover 125-630A
Escutcheon black type B for Sircover 125-630A IP65

44095016

Escutcheon black type B for Sircover 125-630A IP65
12,80" x 12,80" filter fan - 115Vac - 285.3 cfm - RAL 7035 - Type 12

FF20A115UE1

12,80" x 12,80" filter fan - 115Vac - 285.3 cfm - RAL 7035 - Type 12
5,90" x 5,90" filter fan - 24Vdc - 20.6 cfm - RAL 9005 - Type 3R - IP55

FF12D24NN53

5,90" x 5,90" filter fan - 24Vdc - 20.6 cfm - RAL 9005 - Type 3R - IP55

How to Install the CSD243010SS6 Controller

This guide provides step-by-step instructions for installing and configuring the CSD243010SS6 Controller.

Estimated time: 45m

Tools needed:

Screwdriver, Wire strippers, Multimeter

Supplies needed:

Mounting screws, Terminal connectors

  1. Mount the controller

    Secure the CSD243010SS6 controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.

  2. Connect the wiring

    Use terminal connectors to connect the power supply and input/output wires to the designated terminals on the controller. Ensure all connections are tight and secure.

  3. Verify the connections

    Use a multimeter to check the voltage at the power terminals to ensure the controller is receiving the correct voltage. If the voltage is incorrect, double-check the wiring.

  4. Configure the controller settings

    Access the controller's configuration interface and input the necessary parameters for your application. Follow the on-screen instructions to complete the setup.

  5. Calibrate the controller

    Perform any required calibration procedures as specified in the user manual to ensure accurate operation.
