nVent CSD24206LGEMC - Concept EMC Enclosure Type 4, 24.00x20.00x6.00, Light Gray, Mild Steel
nVent

CSD24206LGEMC

UPC: 783510257293

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent Concept EMC Enclosure Type 4 (SKU: CSD24206LGEMC) is a premium, industrial-grade solution designed to safeguard sensitive electronic components from electromagnetic interference (EMI) and radio frequency interference (RFI). Engineered with a robust mild steel construction and finished in a durable light gray coating, this enclosure provides exceptional shielding performance while maintaining a sleek, professional appearance. The Type 4 rating ensures protection against dust, water, and external contaminants, making it ideal for both indoor and outdoor applications where environmental resilience is critical. EMC enclosures like the Concept series are essential in industries where signal integrity and component reliability are non-negotiable. Common applications include telecommunications infrastructure, industrial control systems, medical equipment, and data centers, where stray EMI can disrupt operations or compromise sensitive electronics. The quarter-turn latches on this enclosure offer quick and secure access for maintenance or component adjustments, reducing downtime in fast-paced environments. Additionally, the enclosure’s modular design allows for easy integration with existing systems, whether mounted on walls, racks, or poles. Manufactured by nVent, a global leader in thermal management and electrical protection solutions, the Concept EMC Enclosure leverages decades of expertise to deliver products that meet stringent industry standards. nVent’s reputation for innovation and reliability ensures that the CSD24206LGEMC is built to withstand the demands of harsh operating conditions while providing consistent performance. The enclosure’s mild steel construction not only offers superior EMI/RFI shielding but also delivers structural integrity, resisting corrosion and physical stress. Selecting the right EMC enclosure involves evaluating factors such as size, material, and environmental ratings. The 24.00x20.00x6.00 inch dimensions of this enclosure provide ample space for housing circuit boards, power supplies, or other critical components, while the Type 4 rating guarantees protection against water ingress (up to 1 meter for 30 minutes) and dust. Professionals in electronics manufacturing, automation, and aerospace industries rely on enclosures like this to comply with electromagnetic compatibility (EMC) regulations, such as those outlined in FCC Part 15 or CE directives. The light gray finish not only enhances visibility in industrial settings but also resists fading and wear over time. Installation is straightforward, with pre-drilled holes for secure mounting and compatibility with standard hardware. For outdoor applications, additional considerations such as UV resistance and temperature fluctuations should be accounted for, and nVent’s enclosures are designed to excel in these scenarios. Whether used in a factory automation system, a telecom hub, or a medical device, the CSD24206LGEMC ensures that your electronics operate without interference, extending the lifespan of your equipment and maintaining compliance with regulatory standards. Trust nVent’s Concept EMC Enclosure to deliver the protection and performance your applications demand.
  • Seams continuously welded and ground smooth
  • Minimum width body flange provides maximum door opening
  • External formed body flange channels away liquids
  • Panel mounting studs fit optional Concept panels and other accessories
  • Mounting holes in back of body for direct mounting or for optional external mounting brackets
  • Removable door with hidden hinges for clean, aesthetic appearance
  • Door opens 210 degrees
  • Corner-formed door
  • Hinge mounting brackets for wire management or optional accessories
  • Stainless steel spring finger EMI/RFI gasket

Specifications

Application
Controls and Drives
Body Thickness
1.21 mm
Body Thickness
18 ga
Body Thickness
16 ga
Color
Gray;LtGray
Color
Light Gray
Color Code
RAL 7035
Concept Panel
CP2420
Conductive Panel
CP2420G
Depth
6
Depth
152
Depth
152 mm
Door Thickness
14 ga
Door Thickness
16 ga
Door Thickness
1.52 mm
Finish
Powder Coated
Height
24 in
Height
610 mm
IP Rating
IP66
Latch Quantity
1
Material
Mild Steel
Material
Steel
Modification Services
Yes
Mounting
Wall Mounting Brackets Available
Mounting
22.50 x 18.50 in
NEMA Rating
4
NEMA Rating
4 Watertight
Panel Size
564 x 462 mm
Panel Size
22.20 x 18.20 in
Product Family
Concept
Protection Rating
NEMA Type 12
Size
24.00x20.00x6.00 in
Type
Mild Steel Wall Mounted Industrial Enclosures
Type Number
Type 4
Weight
32.7 lb
Width
508 mm
Width
20 IN
Package Dimensions (L x W x H)
29 IN x 21.1 IN x 8.1 IN
Package Dimensions (L x W x H)
73.66 cm x 53.594 cm x 20.574 cm
Package Weight (Imperial)
32.700 L
Package Weight (Metric)
14.833 kg
