Contact for Pricing
Overview
- Painted white or conductive finish
- Include a formed flange along any side that is longer than 22.20 in (564 mm)
- Optional wood panels are made of 3/4-in plywood, pre-cut and pre-drilled to install on panel mounting studs in the rear of the cabinet
- RAL 7035 White finish for visibility and corrosion resistance
- Provides increased internal mounting space compared to standard NEMA panels
Specifications
Application | Arc Flash Safety;Controls and Drives;Power Distribution |
Application | Power Distribution; Controls and Drives; Arc Flash Safety |
Color | White |
Finish | Powder Coated |
Gauge | 12 ga |
Height | 1,783 mm |
Height | 70.2 in |
Material | Steel |
Material | Mild Steel |
Modification Services | Yes |
Product Family | Concept |
Size | fits 72.00x36.00 in |
Thickness | 2.66 mm |
Thickness | 12 in |
Thickness | 51.40mm (2.024") |
Type | Painted Steel |
Type | Industrial Panels and Panel Accessories;Painted Steel |
Weight | 77 lb |
Width | 868 mm |
Width | 34.2 in |
Works With | NEMA |
Package Dimensions (L x W x H) | 72 IN x 35.5 IN x 1.75 IN |
Package Dimensions (L x W x H) | 182.88 cm x 90.17 cm x 4.445 cm |
Package Weight (Imperial) | 77.000 L |
Package Weight (Metric) | 34.927 kg |
