Contact for Pricing
Overview
- Door panel is optional
- Mounting hardware is included
- Panel dimensions: 48.00 x 60.00 inches
- Constructed from durable white steel
- Provides a secure mounting surface for HMI components
Specifications
Application | Controls and Drives |
Color | White |
Finish | Powder Coated |
Gauge | 12 ga |
Height | 14.23 in |
Height | 361 mm |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
Mounting Type | Rear door mounting |
Product Family | Concept |
Series | Concept Panel |
Series | Concept |
Size | 48.00x60.00 in. |
Size | 48.00x60.00 |
Size | fits 48.00x60.00 in |
Thickness | 1.9 mm |
Thickness | 14 ga |
Thickness | 51.40mm (2.024") |
Type | Industrial Panels and Panel Accessories |
Type | Steel |
Weight | 7.8 lb |
Width | 482 mm |
Width | 18.98 in |
Works With | NEMA |
Package Dimensions (L x W x H) | 21.75 IN x 17 IN x 0.25 IN |
Package Dimensions (L x W x H) | 55.245 cm x 43.18 cm x 0.635 cm |
Package Weight (Imperial) | 7.800 L |
Package Weight (Metric) | 3.538 kg |
