Overview
- Plastic mounting foot kits are rated for 500 lb (227 kg) maximum load
- Sealing washers are provided with each kit to maintain Type 4 and 12 after installation
- Stainless steel and plastic mounting bracket kits are rated to Type 4X
- All hardware is included
- Suitable for telecommunications, water and wastewater treatment, oil and gas, manufacturing, and renewable energy sectors
Specifications
Accessory Type | Mounting Accessories |
Application | Controls and Drives;Corrosive Environments |
Application | Corrosive Environments; Controls and Drives |
Color | Black |
Depth | 0.6 in |
Depth | 15 mm |
Fastener Thread Size | #3/8-16 |
Finish | Smooth Matte |
Height | 3.06 in |
Height | 44 IN |
L | 1.34 in |
L | 2 in |
Material | Composite;Fiberglass |
Material | Fiberglass |
Modification Services | Yes |
Mounting Type | Field-installable |
Series | CMTGFT |
Size | 3.06x1.34x0.60 |
Size | 3.06x1.34x0.60 inches |
Thickness | 2.66 mm |
Thickness | 12 ga |
Thickness | 51.40mm (2.024") |
Type | External Mounting for Industrial Enclosures |
Weight | 0.5 lb |
Width | 34 mm |
Width | 1.34 in |
Works With | IEC |
Package Dimensions (L x W x H) | 10.4 IN x 8 IN x 1 IN |
Package Dimensions (L x W x H) | 26.416 cm x 20.32 cm x 2.54 cm |
Package Weight (Imperial) | 0.500 L |
Package Weight (Metric) | 0.227 kg |
Q3620PD
, Bulletin Q41Y (QLINE® Type 4X Encl. Panels and Accessories - Composite Panels for ABS and Polyester Type 4X Enclosures) ex2
How to Install the CMTGFT Controller
Step-by-step guide for installing and configuring the CMTGFT Controller for optimal performance.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Attach mounting feet
Fasten the mounting feet onto the rear of the enclosure using the provided bolts, washers, and nuts. Ensure they are securely tightened.
- Mount the controller
Secure the controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect wiring
Use wire strippers to prepare the wires and connect them to the appropriate terminals on the controller. Verify connections with a multimeter to ensure proper voltage.
- Configure settings
Power on the controller and access the configuration menu. Set the desired parameters according to the specifications provided in the user manual.
- Calibrate the controller
Follow the calibration procedure outlined in the user manual to ensure accurate readings and performance. Make adjustments as necessary.
