Overview
- A large hole and rubber plug are provided for keyboard cord and plug
- The hinged cover is supported with flexible cables in the open position
- A left and a right mouse tray slides out from under the keyboard mounting surface
- VELCRO strips with pressure-sensitive adhesive are supplied to attach a keyboard
- An internal mouse storage bracket is provided
- Cover latches with a quarter-turn slotted latch
- Optional Concept handles and lock inserts are available
Specifications
Accessory Type | Shelves, Keyboard Trays and Gland Plates |
Application | Arc Flash Safety;Controls and Drives |
Color | Gray |
Color Code | ANSI 61 |
Depth | 122 mm |
Depth | 4.79 in |
Finish | Powder Coated |
Height | 10 IN |
Height | 44 IN |
Height | 254 mm |
Material | Steel |
Material | Mild Steel |
Material | Mild Steel;Steel |
Max Keyboard Size | 20.20 x 8.00 x 2.34 in |
Modification Services | Yes |
Mounting Type | Surface Mount with 4 bolts |
Product Family | Concept |
Series | Concept |
Size | 10.00x23.30x4.79 in |
Size | 10.00x23.30x4.79 |
Thickness | 1.52 mm |
Thickness | 16 ga |
Thickness | 51.40mm (2.024") |
Type | HMI Enclosure Systems |
Type Number | Type 4 |
Weight | 27 lb |
Width | 592 mm |
Width | 23.3 in |
Package Dimensions (L x W x H) | 29 IN x 11.25 IN x 6 IN |
Package Dimensions (L x W x H) | 73.66 cm x 28.575 cm x 15.24 cm |
Package Weight (Imperial) | 27.000 L |
Package Weight (Metric) | 12.247 kg |
How to Install the Keyboard Box
Complete installation guide for mounting and wiring the Keyboard Box for optimal use.
Estimated time: 30m
Tools needed:
Drill, Screwdriver
Supplies needed:
M6 Screws, Velcro Strips
- Drill mounting holes
Use the square mounting holes on the back surface of the keyboard box as a template to drill holes in the mounting surface.
- Mount the keyboard box
Secure the keyboard box to the mounting surface using M6 screws. Ensure it is firmly attached.
- Secure the keyboard
Attach the keyboard to the keyboard support using the provided Velcro strips for stability.
- Feed cables through routing hole
Route the cables from the keyboard and mouse through the cable routing hole located at the rear of the keyboard box.
- Install the mouse tray
Slide the mouse tray into the desired position on either end of the keyboard box for easy access.
- Insert the mouse
Slide the mouse into the mouse bracket located at the rear of the keyboard box for secure storage.
