nVent CIP33 - Mounting Profile 19-Inch 33U, CIP, 1600x45x29mm, Zinc Plated, Mild Steel
nVent

CIP33

UPC: 783510458522

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent CIP33 (SKU: CIP33) is a robust 19-inch mounting profile designed for floor-standing enclosures, offering a reliable solution for integrating standard 19-inch equipment into industrial and commercial environments. Constructed from durable, 3 mm thick zinc-plated mild steel, this profile ensures longevity and resistance to corrosion, making it suitable for demanding applications. Engineered by nVent, a trusted leader in electrical enclosure solutions, the CIP33 profile is part of the CIP series, specifically developed for the secure and adjustable mounting of 19-inch rack-mountable components. Its dimensions of 1600x45x29mm provide ample vertical space for 33U of equipment, allowing for significant density in your enclosure setup. This profile is ideal for applications where standard 19-inch rack equipment needs to be housed within larger floor-standing cabinets, offering flexibility in both factory and field installations. Key features include versatile 19-inch rack mounting, durable 3mm zinc-plated mild steel construction, and a generous 33U of vertical mounting space. The nVent CIP33 is essential for system integrators, electrical contractors, and IT professionals requiring a secure and organized method for deploying 19-inch equipment in control panels, infrastructure expansions, or data centers.
  • Description: Full height mounting profiles to achieve 482.6 mm (19") mounting requirements on all sides. Fully adjustable in depth.
  • Material: 2 mm zinc plated steel.
  • Pack quantity: 1 pair.
  • Mounting requirements: To be used in conjunction with CIB or CID profiles. For partial height mounting the CIWR is required.
  • Designed for floor-standing enclosures

Specifications

Application
Factory Automation and Process Control; Controls and Drives
Color
Unpainted
Consist of
19-Inch Mounting Profiles; Mounting Components and Instruction Manual
Construction
14 gauge
Depth
29 mm
Depth
1.14 in
Enclosure Material
Mild Steel
Finish
Zinc Plated
Height
63 in
Height
1,600 mm
Height
1,502 mm
Material
Mild Steel
Package Quantity
2
Product Family
Free-Standing
Rack Units
33 U
Size
59.13 x 1.77 x 1.14 inch
Thickness
2 mm
Thickness
14 ga
Type
IEC Enclosure Accessories
Type
Mounting
Weight
7.05 lb
Weight
3.2 kg
Width
45 mm
Width
1.77 in
Works With
IEC
Package Weight (Imperial)
7.100 L
Package Weight (Metric)
3.221 kg
