Contact for Pricing
Overview
- Colour: Black, Orange
- Design: Infeed, with through wiring 2-pole cables
- Description: To save time and easily mount the compact LED lights, use these pre-fabricated cables.
- Through-wiring design with 1.5m connection cable
- UL approved for industrial applications
- Integrated mini-connector for door switch activation without additional wiring
Specifications
Application | Controls and Drives; Power Distribution |
Color | Black |
Connection Type | Through wiring, 1.5m cable |
Finish | Smooth Matte |
Length | 39.37 in |
Length | 1,000 mm |
Material | Plastic |
Material | PC-ABS |
Mounting Type | Magnet, screw, rack snap-in |
Nominal Voltage | 250 V |
Operating Temperature | 140-140 °F |
Operating Temperature | 60-60 °C |
Product Family | IEC General Accessories |
Series | CELC |
Size | 1000mm |
Type | Lighting and Sockets |
Weight | 0.3 kg |
Weight | 0.68 lb |
Works With | IEC |
Package Dimensions (L x W x H) | 9.8 IN x 6.9 IN x 1 IN |
Package Dimensions (L x W x H) | 24.892 cm x 17.526 cm x 2.54 cm |
Package Weight (Imperial) | 0.680 L |
Package Weight (Metric) | 0.308 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the Compact Enclosure Light CELC1001TBUL
This guide provides step-by-step instructions for installing and wiring the Compact Enclosure Light CELC1001TBUL safely and effectively.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Copper conductors, Terminal connectors
- Turn off the power supply
Ensure the mains power is turned off before beginning any installation work to prevent electric shock.
- Mount the light fixture
Securely mount the LED luminaire to a stable, flat surface using the appropriate mounting screws, ensuring it is level and firmly attached.
- Connect the power supply
Connect the power supply to the luminaire as indicated in the installation diagrams, ensuring to use only copper conductors and that the circuit is protected with a suitable branch circuit protective device.
- Wire multiple fixtures (if applicable)
If connecting multiple luminaires in series, ensure to connect them as shown in the diagrams, with a maximum of four fixtures in a series.
- Verify the installation
Check that the light fixture is securely mounted and functions properly by turning the power back on and testing the operation of the light.
