Overview
- Meet UL Type 1 construction requirements when installed in an nVent HOFFMAN enclosure
- Top and bottom barrier plates included to provide a full-depth separation
- Main barrier plate has a 6-inch extender to add flexibility when mounting
- Quick release hinges used to secure the main barrier plate to the top barrier plate to simplify installation
- Ground stud on the main barrier plate
- Designed to fit the following bulletins: A21 (excluding CPX enclosures), A28M2, A28MM, A4L3D, A4L3, A4L, A21S4 (excluding CPX enclosures), A28S4, A4S2, A4S3, A4SL
- Mount to the welded or removable centerpost of an enclosure; the barrier panel cannot be installed in free-stand or floor-mount enclosures without a centerpost
- Mounting hardware and brackets included
Specifications
Application | Controls and Drives; Power Distribution |
Cable Entry | No |
Color | White |
Finish | Powder Coated |
Fits Enclosure | 90 x 18 |
Height | 66 mm |
Height | 2.6 in |
Material | Steel |
Material | Mild Steel |
Mounting | Mounts to centerpost |
Mounting Type | Unibody Free-Stand with Centerpost |
NEMA Rating | Type 1 |
Size | 89.80 x 17.80 x 2.60 |
Size | A=90, C=18 |
Thickness | 1.9 mm |
Thickness | 14 ga |
Type | Industrial Panels and Panel Accessories |
Weight | 52.65 lb |
Width | 452 mm |
Width | 17.8 in |
Works With | NEMA |
Package Dimensions (L x W x H) | 81.5 IN x 18.5 IN x 3 IN |
Package Dimensions (L x W x H) | 207.01 cm x 46.99 cm x 7.62 cm |
Package Weight (Imperial) | 52.650 L |
Package Weight (Metric) | 23.882 kg |
How to Install the A90BP18 Controller
This guide provides step-by-step instructions for mounting, wiring, and configuring the A90BP18 Controller.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the A90BP18 controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the wiring
Use terminal connectors to attach the necessary power and signal wires to the controller. Ensure all connections are tight and secure.
- Verify the installation
Use a multimeter to check the voltage at the controller's input terminals. Ensure the voltage matches the specifications outlined in the documentation.
- Configure the controller
Follow the programming instructions in the user manual to set up the desired operational parameters for the A90BP18 controller.
- Calibrate the controller
Perform any necessary calibration procedures as outlined in the documentation to ensure accurate operation.
