Overview
- Panel mounting hardware is furnished with all enclosures which accept these panels
- ANSI 61 gray polyester powder coating for corrosion resistance
- Removable door with unique lift-off hinges for easy access
- Quick-release latches and oil-resistant gasket for secure sealing
- External welded-on mounting brackets for straightforward installation
- External welded-on mounting brackets for easy installation
- UL-listed for compliance with safety and performance standards
- Optional conductive, aluminum, or painted steel panels available
- Bonding provision on door for grounding compliance
- Compatible with terminal block kits and other accessories
Specifications
Accessory Type | Panels and Panel Accessories |
Application | Controls and Drives; Power Distribution; Corrosive Environments |
Application | Controls and Drives;Corrosive Environments;Power Distribution |
Color | Unpainted |
Color | ANSI 61 gray |
Finish | Galvanized |
Height | 149 mm |
Height | 5.88 in |
Material | Zinc Galvanized Mild Steel |
Material | Mild Steel, Galvanized |
Material | Mild Steel;Zinc |
Material | Mild Steel |
Modification Services | Yes |
Mounting Type | Wallmount |
Panel Size | 5.88 x 5.88 in |
Panel Size | 149 x 149 mm |
Series | Hoffman |
Size | 7x7 |
Thickness | 1.9 mm |
Thickness | 14 in |
Thickness | 51.40mm (2.024") |
Type | Industrial Panels and Panel Accessories |
Weight | 0.7 lb |
Width | 5.88 in |
Width | 149 mm |
Works With | NEMA |
Package Dimensions (L x W x H) | 9.5 IN x 6.25 IN x 0.5 IN |
Package Dimensions (L x W x H) | 24.13 cm x 15.875 cm x 1.27 cm |
Package Weight (Imperial) | 0.700 L |
Package Weight (Metric) | 0.318 kg |
How to Install the A40P30 Panel Enclosure
This guide provides step-by-step instructions for installing and configuring the A40P30 panel enclosure for optimal performance.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Wire connectors
- Mount the enclosure
Secure the A40P30 panel enclosure to a suitable surface using the provided mounting screws. Ensure it is level and stable.
- Connect power supply
Use wire connectors to connect the power supply wires to the designated terminals inside the enclosure. Ensure all connections are tight and secure.
- Verify electrical connections
Use a multimeter to check the voltage at the terminals to ensure proper power supply. Confirm that the readings are within the specified range.
- Configure settings
Access the control panel of the A40P30 and configure the necessary settings according to your operational requirements.
- Calibrate the system
Follow the calibration procedure outlined in the user manual to ensure the system operates accurately and efficiently.
