Overview
- Unique keyhole screw slots for easy installation
- Plated steel screws included to mount to pull box
- Compatible with Type 1 Pull Box accessories
- Maintains grounding between main enclosure and extender
- Extenders are finished with paint over plated surfaces
Specifications
Application | Power Distribution |
Color | Gray |
Color Code | ANSI 61 |
Depth | 13 IN |
Depth | 4 in |
Depth, Maximum | 4 |
Depth, Minimum | 4 |
Finish | Galvanized |
Height | 44 IN |
Height | 6 IN |
IP Rating | IP30 |
Material | Galvanized Steel |
Material | Mild Steel |
Material | Steel |
Mounting Type | Sliding design |
NEMA Rating | Type 1 |
Protection Rating | NEMA Type 1 |
Size | 6.00 x 6.00 x 4.00 inches (152 x 152 x 102 mm) |
Style | Galvanized |
Thickness | 16 ga |
Thickness | 51.40mm (2.024") |
Type | General Accessories |
Type | Commercial Accessories |
Weight | 2.3 lb |
Width | 152 mm |
Width | 6 IN |
Works With | NEMA |
