Overview
- Drip shield top and seam-free sides, front, and back
- Slip-on removable cover
- Embossed mounting holes on back of enclosure
- Provision for padlocking
- No gasketing or knockouts
- 16 or 14 gauge plated steel
Specifications
Application | Power Distribution |
Color | Gray |
Color Code | ANSI 61 |
Depth | 13 IN |
Depth | 12 |
Depth | 305 |
Finish | Galvanized |
Height | 4 IN |
Height | 102 mm |
IP Rating | IP32 |
Material | Mild Steel;Steel |
Material | Mild Steel |
Modification Services | Yes |
NEMA Rating | 3R Weather-resistant, except dust |
Protection Rating | NEMA Type 3R |
Size | 4.00x4.00x12.00 in |
Thickness | 16 ga |
Thickness | 1.52 mm |
Thickness | 51.40mm (2.024") |
Type | Trough |
Type | Commercial Wiring Troughs;Trough |
Type Number | Type 3R |
Weight | 5.6 lb |
Width | 4 |
Width | 102 |
Width | 23 IN |
Wireway | Wiring Troughs |
Package Dimensions (L x W x H) | 15 IN x 5.2 IN x 4.7 IN |
Package Dimensions (L x W x H) | 38.1 cm x 13.208 cm x 11.938 cm |
Package Weight (Imperial) | 5.600 L |
Package Weight (Metric) | 2.540 kg |
