Overview
- Compression-molded fiberglass has outstanding chemical- and temperature-resistance qualities and exhibits excellent weatherability and physical properties
- Fiberglass is easily punched, drilled, filed or sawed
- Gasket assures water-tight and dust-tight seal
- Polyester mounting brackets and stainless steel attachment screws are provided with each enclosure
- Scratch-resistant polycarbonate windows are permanently bonded in place
- Molded-in-place threaded brass inserts and plated steel screws are provided for mounting optional panels and terminal block kits
- Removable hinged cover attached to body with Type 316 stainless steel hinge pin
- Screw-cover enclosures are secured with two captivated Type 316 stainless steel slotted cover screws
- Enclosures with quick-release latches have corrosion-resistant polyester latches located in corners that provide unobstructed access to enclosure
- Hinge pin and bail are corrosion-resistant Type 316 stainless steel
Specifications
Aluminum Panel | A16P14AL |
Application | Controls and Drives;Corrosive Environments |
Color | Gray |
Color | Grey |
Color | Light Gray |
Color Code | RAL 7035 |
Cover Style | Solid Screw |
Depth | 8 mm |
Depth | 203 mm |
Finish | Smooth Matte |
Height | 406 mm |
Height | 16 in |
IP Rating | IP66 |
Material | Fiberglass |
Material Quality | Fiberglass |
Modification Services | Yes |
Mounting | 16.94 x 12.00 in |
Mounting | Wall Mounting Brackets Available |
NEMA Rating | 4X |
NEMA Rating | 4X Watertight, corrosion-resistant |
Nema Rating | Type 12 |
Overall Dimensions | 114 x 88 mm |
Overall Dimensions | 16.55 x 14.55 in |
Panel Size | 14.75 x 12.88 in |
Panel Size | 375 x 327 mm |
Protection Rating | NEMA Type 12 |
Size | 16.00x14.00x8.00 |
Size | 16.00x14.00x8.00 in |
Steel Panel | A16P14 |
Thickness | 0.12 in |
Thickness | 51.40mm (2.024") |
Type | Solid Screw Cover |
Type | Fiberglass and Thermoplastic Wall Mounted Industrial Enclosures |
Type Number | Type 13 |
Weight | 10.5 lb |
Width | 356 mm |
Width | 14 IN |
Package Dimensions (L x W x H) | 18.6 IN x 16.5 IN x 10.8 IN |
Package Dimensions (L x W x H) | 47.244 cm x 41.91 cm x 27.432 cm |
Package Weight (Imperial) | 10.500 L |
Package Weight (Metric) | 4.763 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
