Overview
- Seams continuously welded and ground smooth
- Bonding provision on cover
- Oil-resistant gasket
- Weldnuts provided for mounting optional panels and terminal block kits in size 6.00 x 4.00 in. (152 x 102 mm) and larger
- External wall-mounting brackets for easy installation
- External wall-mounting brackets for easy installation
Specifications
Application | Controls and Drives |
Color | Gray |
Color Code | ANSI 61 |
Conductive Panel | A10P8G |
Depth | 13 IN |
Depth | 6 in |
Depth, Maximum | 6 |
Depth, Minimum | 6 |
Finish | Powder Coated |
Height | 44 IN |
Height | 10 IN |
IP Rating | IP65 |
Material | Mild Steel;Steel |
Material | G-90 Grade Galvanized Steel |
Material | Steel |
Modification Services | Yes |
Mounting | 10.75 x 6.00 in |
Mounting | Wall Mounting Brackets Available |
NEMA Rating | 12 |
Nema Rating | Type 12 |
Nema Rating | Type 12/13 |
Overall Dimensions | 114 x 88 mm |
Overall Dimensions | 11.50 x 8.28 in |
Panel | A10P8 |
Panel Size | 8.75 x 6.88 in |
Panel Size | 72.00 x 72.00 in |
Protection Rating | NEMA Type 12 |
Series | SC Box |
Size | 10.00x8.00x6.00 in |
Size | 10.00x8.00x6.00 |
Size | 10.00x8.00x6.00 inch |
Thickness | 14 ga |
Thickness | 51.40mm (2.024") |
Type | Mild Steel Industrial Terminal and Junction Boxes |
Type | Mild Steel Terminal and Junction Boxes |
Type Number | Type 13 |
Weight | 9 lb |
Width | 203 mm |
Width | 8 in |
Package Dimensions (L x W x H) | 11.5 IN x 8.25 IN x 6 IN |
Package Dimensions (L x W x H) | 29.21 cm x 20.955 cm x 15.24 cm |
Package Weight (Imperial) | 9.300 L |
Package Weight (Metric) | 4.219 kg |
Frequently Asked Questions
What NEMA and IP ratings does the nVent A10086SC enclosure have?
The nVent A10086SC enclosure is rated NEMA/EEMAC Type 12 and 13, and IEC 60529 IP65.
What material is the nVent A10086SC enclosure made from?
The enclosure is constructed from 14-gauge mild steel with an ANSI 61 gray powder-coated finish.
What are the external dimensions of the nVent A10086SC enclosure?
The external dimensions of the nVent A10086SC enclosure are 10.00 inches in height, 8.00 inches in width, and 6.00 inches in depth.
Does the nVent A10086SC enclosure have knockouts?
No, the nVent A10086SC enclosure does not include any knockouts.
What type of cover does the nVent A10086SC enclosure feature?
The nVent A10086SC enclosure features a solid, screw-on cover.
How to Install the Grounding Kit for E9PBY25M
This guide provides step-by-step instructions for installing the grounding kit for the E9PBY25M, ensuring proper electrical continuity and safety.
Estimated time: 15m
Tools needed:
Screwdriver, Torque wrench
Supplies needed:
10-32x5/8 screws, Keps nuts, 10-32 hex nuts, Lockwashers, Ground wire, Grounding label
- Insert the mounting screw
Insert the 10-32x5/8 screw through the designated hole in the panel.
- Secure the screw
Tighten the screw using a keps nut, ensuring that the nut penetrates into the paint for proper electrical continuity.
- Attach the ground wire
Connect the ground wire and secure it using a 10-32 hex nut.
- Install the lockwasher
Place a lockwasher under one of the screws securing the panel to ensure grounding between the panel and the enclosure. Do not exceed a torque of 30 in-lbs.
- Apply the grounding label
Attach the included grounding label adjacent to the bolt as indicated in the installation instructions.
