Woodhead 68W47 - Watertite® Male Receptacle with Locking Blade, Single Flip Coverplate, 2 Pole/3 Wire, NEMA L5-30, 125V
Woodhead

68W47

Alternate Item Number: 1301470157

UPC: 786788714628

Documents & Media
Technical DrawingSpecification Sheet

Contact for Pricing

Overview

The Woodhead Watertite® Male Receptacle with Locking Blade (SKU: 68W47) delivers a rugged, weather-resistant power connection engineered for harsh industrial environments. This NEMA L5-30 rated receptacle supports 30 Amp, 125 Volt applications with a 2 Pole/3 Wire configuration, including grounding for enhanced safety. Its Watertite® design ensures superior ingress protection against water, dust, and corrosive elements, making it ideal for wet locations, high-pressure washdowns (up to 1000psi), and outdoor or marine applications. The locking blade mechanism prevents accidental disconnections, critical in high-vibration or mobile equipment scenarios. The single flip coverplate provides easy access while protecting the receptacle from contaminants when not in use. Key features include color-coded ¼" terminal screws for quick wiring, tri-drive screw terminals compatible with straight blade, Phillips, and square-drive drivers, and a transparent wiring guide to verify wire strand placement. The F3 body size (¾") accommodates standard cord grips, while the nickel-plated brass blades and stainless steel face screws ensure long-term durability. UL File No. E68122 and CSA File No. LR6837 certified, this receptacle meets NSF/ANSI/3-A 14159-1 standards for food processing and sanitary environments. Applications include manufacturing plants, construction sites, agricultural equipment, and utility services where reliable, protected power connections are essential.
  • NEMA L5-30 rating: 30A, 125V, 2 Pole/3 Wire with grounding
  • Watertite® design resists water, dust, and high-pressure washdowns (1000psi)
  • Locking blade mechanism prevents accidental disconnections in high-vibration environments
  • Single flip coverplate for easy access and environmental protection
  • F3 body size (¾") with tri-drive terminals and transparent wiring guide for secure installation

Specifications

Amperage Rating
30 A
Brand Name
Woodhead
Connection Type
Locking Blade
Current Rating
30 A
Environmental Conditions
IP67
Material
Durable Industrial Materials
Nema Rating
NEMA L5-30
Number Of Poles
2-pole/3-wire
Number of Poles
2;3-wire
Poles
2P+G
Series
Watertite
Sub Brand
Watertite
Type
Inlet
Voltage Rating
125 V
Package Weight (Imperial)
1.500 L
Package Weight (Metric)
0.680 kg
