Woodhead 65W64 - Watertite® Receptacle Flip Coverplate with California Style Locking Blade, 3 Pole/4 Wire, Non-NEMA, 250V
Woodhead

65W64

Alternate Item Number: 1301470123

UPC: 786788348465

Documents & Media
Specification Sheet

Contact for Pricing

Overview

The **Woodhead Watertite® 65W64** is a 3-pole/4-wire, non-NEMA compliant flip coverplate rated at 250V, designed for harsh industrial environments where moisture, dust, and mechanical stress threaten electrical system integrity. Part of Woodhead’s trusted Watertite® line, this coverplate delivers IP55 to IP69K ingress protection and NEMA Types 1, 2, 3, 4, 4X, 5, 6, 6P, and 12 compliance, making it ideal for food processing, oil & gas, manufacturing, and outdoor installations. The flip cover design allows immediate access to receptacles while maintaining a watertight seal when closed, ensuring compliance with stringent environmental standards. The California-style locking blade configuration prevents accidental disconnection of power cords under load—a critical safety feature in high-vibration or high-traffic environments such as machine shops, control panels, and outdoor workstations. Constructed from **Nylon faceplate**, **nickel-plated brass contacts**, and **stainless steel face screws**, the 65W64 offers exceptional durability and corrosion resistance across a wide operating temperature range from **-40°C to 75°C**. Key features include a **39.62mm (1.56") opening** for standard industrial receptacles, **tri-drive terminal screws** for tool-free wiring, and a **floating blade construction** for self-alignment and reduced wear. Certified by **UL (E68122)**, **CSA (LR6837)**, and **NSF/ANSI/3-A 14159-1**, the 65W64 meets rigorous safety and hygiene standards required in regulated industries. Typical applications include food & beverage processing, oil & gas facilities, manufacturing automation, outdoor/marine installations, and utilities/telecommunications. The 65W64 is a drop-in solution for new installations or retrofits, designed for quick mounting and easy maintenance. Trust Woodhead’s decades of expertise in industrial electrical connectivity for products that protect, perform, and endure in the most challenging conditions.
  • 3-pole/4-wire, non-NEMA compliant, rated 250V for industrial applications
  • IP55 to IP69K ingress protection and NEMA Types 1, 2, 3, 4, 4X, 5, 6, 6P, 12 compliance
  • California-style locking blade prevents accidental disconnection under load
  • Operating temperature range: -40°C to 75°C with 30°C max temperature rise at full rated current
  • Constructed from Nylon faceplate, nickel-plated brass contacts, and stainless steel hardware for durability and corrosion resistance

Specifications

Amperage Rating
50 A
Brand Name
Woodhead
Environmental Conditions
IP67
Nema Rating
Non-NEMA
Number Of Poles
3-pole/4-wire
Number of Poles
3;4-wire
Poles
3P/4W
Sub Brand
Watertite
Type
Receptacle
Voltage Rating
250 V
Package Weight (Imperial)
1.000 L
Package Weight (Metric)
0.454 kg
