Woodhead 5766 - Safeway® Plug, 2 Pole/3 Wire, NEMA 7-15, 277V
Woodhead

5766

Alternate Item Number: 1301440069

UPC: 786788701093

Documents & Media
Technical DrawingSpecification Sheet

Contact for Pricing

Overview

The Woodhead Safeway® Plug, SKU 5766, is a 2-pole, 3-wire industrial electrical connector rated for 277V and compliant with NEMA 7-15 standards. This plug is constructed with a rugged nylon body, offering exceptional durability and performance in demanding industrial environments. The Safeway® series is known for its reliable power delivery and enhanced safety features. The 2-pole configuration provides essential conductors for power, while the 3-wire setup includes a vital ground connection, crucial for protecting equipment from electrical surges and improving overall operational safety. Its NEMA 7-15 rating ensures compatibility with specific industrial enclosure types. Applications include powering high-voltage industrial machinery, HVAC systems, and large motor controls where secure and dependable 277V connections are paramount. Woodhead's commitment to engineering excellence ensures straightforward installation and a long service life, with a housing designed to protect internal components from dust, moisture, and mechanical impact. Key features include robust construction, 2-pole/3-wire configuration, 277V voltage rating, NEMA 7-15 compatibility, and enhanced safety through grounding. This plug is manufactured in the US.
  • 2-Pole/3-Wire Configuration
  • 277V Voltage Rating
  • NEMA 7-15 Compliant
  • Rugged Nylon Body Construction
  • Industrial-Grade Durability

Specifications

Amperage Rating
15 A
Brand Name
Woodhead
Environmental Conditions
None
Nema Rating
NEMA 7-15
Number Of Poles
2-pole/3-wire
Number of Poles
2
Poles
2P+G
Series
Safeway
Sub Brand
Safeway
Type
Plug
Voltage Rating
277 V
Package Weight (Imperial)
1.187 L
Package Weight (Metric)
0.538 kg
