Woodhead 5469 - Safeway® Connector, 2 Pole/3 Wire, NEMA 6-20, 250V
Woodhead

5469

Alternate Item Number: 1301440063

UPC: 786788703202

Documents & Media
Technical DrawingSpecification Sheet

Contact for Pricing

Overview

The Woodhead Safeway® Connector (SKU: 5469) is a 2 Pole/3 Wire connector designed for industrial power distribution. It features a NEMA 6-20 configuration and a 250V rating, ensuring reliable power transmission for demanding applications. Constructed with a durable nylon housing, this connector meets stringent industry standards for safety and performance. The 2-pole + ground (2P+G) design provides balanced power and essential safety grounding. Its physical characteristics include nickel-plated brass plug blades and connector contacts, stainless steel face screws, and a nylon face insert. The cord clamp screws are steel, zinc-plated, and the wire saddle clamp is brass. Designed for wire ranges of .335 to .640 inches, it operates reliably in temperatures from -40°C to 75°C. The connector is built to withstand a maximum 30°C temperature rise at full rated current after 50 cycles of overload at 150% of rated current with a 75% power factor. This makes it suitable for heavy machinery, control panels, and high-power equipment in manufacturing, warehouses, and construction sites. Woodhead's Safeway® series is recognized for its compliance with UL and CSA certifications, offering peace of mind for professionals prioritizing safety and performance.
  • NEMA 6-20 configuration for 250V applications
  • 2 Pole/3 Wire (2P+G) design for balanced power and grounding
  • Durable nylon housing for industrial environments
  • Nickel-plated brass contacts for reliable conductivity
  • UL and CSA certified for safety and performance

Specifications

Amperage Rating
20 A
Brand Name
Woodhead
Environmental Conditions
None
Material
High-strength metal
Nema Rating
NEMA 6-20
Number Of Poles
2-pole/3-wire
Number of Poles
2
Poles
2P+G
Series
Safeway
Sub Brand
Safeway
Type
Connector
Voltage Rating
250 V
Package Weight (Imperial)
1.187 L
Package Weight (Metric)
0.538 kg
