Woodhead 4700DW - Safeway® Duplex Heavy - Duty Spec - Grade Receptacle with Locking Blade, 2 Pole/3 Wire, NEMA L5-15, 125V
Woodhead

4700DW

Alternate Item Number: 1301480074

UPC: 786788703929

Documents & Media
Specification Sheet

Contact for Pricing

Overview

The Woodhead Safeway® Duplex Heavy-Duty Spec-Grade Receptacle, SKU 4700DW, is engineered for demanding industrial applications requiring secure and reliable power connections. This receptacle features a NEMA L5-15 configuration, specifying a 2-pole, 3-wire grounding system designed for 125V and 15A service. The integrated locking blade mechanism is a critical safety feature, preventing accidental disconnection of power cords under load, essential for maintaining operational continuity in high-vibration or high-traffic areas. Constructed to stringent Spec-Grade standards, the 4700DW utilizes durable nylon housing and nickel-plated brass contacts for superior wear, impact, and corrosion resistance, ensuring long-term performance in harsh conditions. Its duplex design provides two outlets within a single-gang footprint, optimizing space efficiency for power distribution panels, machinery, and workstations. This heavy-duty construction makes it ideal for manufacturing, heavy industry, and construction sectors where dependable power is paramount. Woodhead, a trusted name in industrial electrical components, delivers exceptional quality with the Safeway® line. The 4700DW is designed for straightforward installation into existing electrical systems. Professionals rely on Woodhead for products meeting rigorous safety and performance requirements. Key features include: Secure Locking Blade: Prevents accidental plug disengagement. NEMA L5-15 Rating: Standardized 125V, 15A, 2-pole, 3-wire grounding. Spec-Grade Construction: Superior durability and longevity. Duplex Configuration: Two outlets in a single-gang unit. Heavy-Duty Materials: Resists wear, corrosion, and environmental stressors. Trusted Woodhead Quality: Ensures reliability and safety. Applications include powering industrial equipment, machine tools, portable generators, and temporary power setups on construction sites, ensuring productivity and safety in demanding environments.
  • NEMA L5-15 configuration for 125V, 15A, 2-pole, 3-wire grounding.
  • Secure locking blade prevents accidental plug disengagement.
  • Spec-Grade construction for superior durability and longevity.
  • Duplex design provides two outlets in a single-gang unit.
  • Heavy-duty nylon housing and nickel-plated brass contacts resist wear and corrosion.

Specifications

Amperage Rating
15 A
Brand Name
Woodhead
Current Rating
15 A
Environmental Conditions
None
Nema Rating
NEMA L5-15
Number Of Poles
2-pole/3-wire
Number of Poles
2;3-wire
Poles
2P+G
Poles
2P/3W
Series
Safeway
Sub Brand
Safeway
Type
Receptacle
Voltage Rating
125 V
Package Weight (Imperial)
1.312 L
Package Weight (Metric)
0.595 kg
