TE Connectivity 225430-E - 8 Position Circular Connector, Cable-to-Board, Printed Circuit Board, Power, Signal & High Speed Data, Board Mount, A Code, M8 Connector
TE Connectivity

225430-E

Documents & Media
Full Engineering DrawingSpecification Sheet

Contact for Pricing

Minimum Qty: 200

Multiplier: 200

*Contact for lower quantities*

Overview

The TE Connectivity 225430-E is an 8-position circular connector designed for reliable cable-to-board connections in industrial applications. This board-mount connector supports power, signal, and high-speed data transmission, making it ideal for demanding environments. Featuring an A-code M8 design, it ensures robust performance and durability. The connector is engineered to meet the needs of industrial automation, telecommunications, and other high-performance applications where dependable connectivity is critical. Its compact design and high-quality construction ensure seamless integration into various systems, providing long-term reliability and efficiency. This M8 connector, part of TE Connectivity's extensive range of industrial interconnect solutions, offers a secure and dependable interface for transmitting power, signal, and high-speed data. The 8-position configuration allows for complex wiring schemes, while the A-code ensures correct mating and prevents misconnections. Ideal for applications requiring robust electrical connections in challenging industrial settings, the 225430-E is built to withstand harsh operational conditions. Its cable-to-board mounting style simplifies integration into control panels, machinery, and other equipment. Engineered for precision and reliability, TE Connectivity's components are trusted by professionals for mission-critical electrical interface requirements. The 225430-E exemplifies this commitment to quality, offering a durable and efficient solution for modern industrial automation and communication networks.
  • 8-Position A-Code M8 Circular Connector
  • Cable-to-Board, Board Mount Design
  • Supports Power, Signal, and High-Speed Data
  • Robust Performance for Industrial Applications
  • Durable Construction for Demanding Environments

Specifications

Amperage Rating
3 A
Connection Type
Cable-to-Board
Mounting
Board Mount
Mounting Type
Board Mount
Number of Conductors
8
Poles
8
Series
A Code M8
Temperature Rating
-25 - 85 °C
Type
Plug
