TE Connectivity 1SNK712011R0000 - - Find all the features of the ZK16 terminal block with the added option of distributing or branching 3 conductors, - ZK16-3P is perfectly adapted to solar applications: 1250 V DC (1000 V AC) IEC, 1000 V UL.
TE Connectivity

1SNK712011R0000

Alternate Item Number: 1SNK712011R0000

Documents & Media
Specification Sheet

Contact for Pricing

Minimum Qty: 180

Multiplier: 180

*Contact for lower quantities*

Overview

The TE Connectivity ZK16-3P terminal block, SKU 1SNK712011R0000, is engineered for reliable electrical distribution and branching in solar energy systems. This terminal block facilitates the connection of three conductors, offering enhanced flexibility for solar installations. It meets stringent voltage requirements, rated at 1250 V DC (1000 V AC) per IEC standards and 1000 V per UL standards. Manufactured in Germany by TE Connectivity, a recognized leader in connectivity solutions, the ZK16-3P ensures dependable performance in renewable energy applications. Its design supports efficient power management and contributes to the overall reliability of solar power generation infrastructure. The ZK16-3P terminal block is suitable for applications requiring robust and safe conductor management at high DC voltages. Specifically, the ZK16 terminal block, with the added option of distributing or branching 3 conductors, is perfectly adapted to solar applications. The voltage ratings are 1250 V DC (1000 V AC) according to IEC standards and 1000 V according to UL standards. This product is designed to handle the specific demands of solar power systems.
  • Distributes or branches 3 conductors
  • Rated 1250 V DC (1000 V AC) IEC
  • Rated 1000 V UL
  • Specifically adapted for solar applications
  • Manufactured by TE Connectivity

Specifications

Color
Light Grey
Connection Type
Screw Terminal
Connection Type
Terminal Block
Poles
3P
Poles
3 conductors
Series
ZK16
Series
ZK16 Series
Series
ZK16-3P
Voltage Rating
1250 V DC (1000 V AC) IEC, 1000 V UL
Voltage Rating
1250 V DC (1000 V AC) IEC / 1000 V UL
Voltage Rating
1250V DC (1000V AC)
