TE Connectivity 1SNK710067R0000 - Specially designed for high voltage utility scale solar power plants: - Rated voltage of 1500 V DC IEC and 1000 V DC UL, - Pre-mounted end section with light grey color specific to this application, - Improved design with ribs to increase creepage distance, - Compact solution only 2 mm thicker than normal product, - 3 connections configuration for easy grouping: 2 inputs / 1 output or 1 input / 2 outputs, - Compatible with JB12 jumpers to interconnect multiple terminal blocks.
TE Connectivity

1SNK710067R0000

Alternate Item Number: 1SNK710067R0000

Documents & Media
Specification Sheet

Contact for Pricing

Minimum Qty: 20

Multiplier: 20

*Contact for lower quantities*

Overview

The TE Connectivity 1SNK710067R0000 is a high-performance terminal block specifically engineered for utility-scale solar power plants. Rated for 1500V DC IEC and 1000V DC UL, this terminal block ensures reliable electrical connections in demanding solar applications. Its pre-mounted end section with a distinctive light grey color is tailored for solar installations, while the improved design with ribs enhances creepage distance for superior safety. The compact solution is only 2 mm thicker than standard products, making it ideal for space-constrained environments. Featuring a flexible 3-connection configuration, it supports both 2-input/1-output and 1-input/2-output setups, allowing for easy grouping and system scalability. Compatible with JB12 jumpers, this terminal block enables seamless interconnection of multiple units, optimizing installation efficiency. Manufactured by TE Connectivity, a trusted leader in connectivity solutions, this terminal block delivers durability, performance, and compliance with industry standards.
  • Rated for 1500V DC IEC and 1000V DC UL for high-voltage solar applications
  • Pre-mounted end section with light grey color for solar-specific identification
  • Improved design with ribs to increase creepage distance and enhance safety
  • Compact solution, only 2 mm thicker than standard terminal blocks
  • Flexible 3-connection configuration for easy grouping and system scalability

Specifications

Color
Light Grey
Connection Type
Terminal Block
Poles
3 connections (2 inputs / 1 output or 1 input / 2 outputs)
Voltage Rating
1500 V DC IEC / 1000 V DC UL
