TE Connectivity 1SNK710020R0000 - Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
TE Connectivity

1SNK710020R0000

Alternate Item Number: 1SNK710020R0000

Documents & Media
Specification Sheet

Contact for Pricing

Minimum Qty: 20

Multiplier: 20

*Contact for lower quantities*

Overview

The TE Connectivity 1SNK710020R0000 is a high-performance industrial connector engineered for demanding applications where both electrical integrity and space efficiency are paramount. This connector boasts an impressive voltage rating of 1000 V AC / DC, meeting IEC standards, and 600 V UL. Its compact dimensions are a key design advantage, allowing for integration into space-constrained electrical enclosures and machinery. A standout feature is the up-front, flat marker zone. This dedicated area provides exceptional visibility for marking, accommodating up to eight digits or allowing for an increased font size, which significantly enhances traceability and simplifies inventory management and maintenance procedures. Manufactured by TE Connectivity, a recognized leader in connectivity solutions, the 1SNK710020R0000 is built to deliver reliable performance in challenging industrial settings. Its robust construction ensures dependable operation in power distribution, automation systems, and industrial machinery. The UNSPSC code for this product is 39121410, and it is manufactured in Germany (DE).
  • 1000 V AC / DC IEC voltage rating
  • 600 V UL voltage rating
  • Compact dimensions for space-saving installations
  • Up-front, flat marker zone for enhanced visibility
  • Supports marking of up to eight digits or larger font sizes

Specifications

Connection Type
Connector
Mounting Type
Panel Mount
Size
Compact
Voltage Rating
1000 V AC/DC
Voltage Rating
1000 V AC/DC (IEC 600 V UL)
Voltage Rating
1000 V AC/DC IEC 600 V UL
