TE Connectivity 1SNK516063R0000 - Combine high performance with compact dimensions: - Connect conductors up to 50 mm² (CB certified) 0 AWG in just 16 mm 0.630 in spacing, - Perfectly adapted to solar applications: 1250 V DC (1000 V AC) IEC and 1000 V UL, - Closed terminal block: no end section needed, optmized rigidity.
TE Connectivity

1SNK516063R0000

Alternate Item Number: 1SNK516063R0000

Documents & Media
Specification Sheet

Contact for Pricing

Minimum Qty: 20

Multiplier: 20

*Contact for lower quantities*

Overview

The TE Connectivity 1SNK516063R0000 terminal block delivers high-voltage reliability in a compact 16mm (0.630 in) footprint, supporting conductors up to 50mm² (0 AWG) with CB certification. Designed for solar and industrial applications, this terminal block meets IEC 1250V DC (1000V AC) and UL 1000V standards, ensuring safe operation in high-voltage environments. Its closed terminal design eliminates the need for end sections, optimizing rigidity and space efficiency while maintaining a rigid structure. The 16mm spacing accommodates dense wiring configurations without compromising performance. The terminal block’s CB certification confirms compliance with international safety standards for electrical equipment, reinforcing its suitability for high-power applications. With a rated voltage of 1250V DC and 1000V AC, it provides robust insulation and dielectric strength for solar arrays, battery storage systems, and high-power distribution networks. The UL 1000V rating further validates its performance in North American markets, ensuring compatibility with stringent regulatory requirements. The closed terminal block design enhances structural integrity by preventing conductor displacement and reducing the risk of short circuits. This feature also simplifies installation by eliminating the need for additional end sections, streamlining the wiring process and reducing material costs. The compact 16mm spacing allows for high-density wiring layouts, maximizing space efficiency in control panels and junction boxes. Ideal for renewable energy systems, this terminal block supports critical applications such as photovoltaic (PV) arrays, energy storage solutions, and grid-tied inverters. Its high-voltage ratings and compact form factor make it a reliable choice for installations where space constraints and electrical safety are paramount. Certified for global compliance, it integrates seamlessly into IEC and UL-rated systems, reducing installation complexity and long-term maintenance costs. Trust TE Connectivity’s precision-engineered components for applications where voltage integrity and compact design are critical.
  • 16mm (0.630 in) spacing for dense wiring configurations
  • Supports conductors up to 50mm² (0 AWG) with CB certification
  • Rated 1250V DC / 1000V AC (IEC) and 1000V UL for high-voltage applications
  • Closed terminal design eliminates need for end sections, optimizing rigidity
  • Ideal for solar applications, battery storage, and industrial high-power systems
