Contact for Pricing
Minimum Qty: 32
Multiplier: 32
*Contact for lower quantities*
Overview
- DIN rail-mounted industrial connector for signal and power transmission
- Designed for harsh environments requiring dependable performance
- Part of TE Connectivity’s industrial connectivity portfolio
- Manufactured in Germany to UNSPSC 39121410 standards
- SKU: 1SNA115914R0700
Specifications
Amperage Rating | 24 Ampere |
Amperage Rating | 24 A |
Application | Circuit Application |
Color | Gray |
Material | Polyamide |
Mounting | TH35-15, TH35-7.5 |
Mounting Type | DIN rail-mounted |
Number Of Terminals | 2 |
Series | D6/8.ST.RS |
Size | 48.3*0.315*3.37 inch |
Size | 48.3*8*85.6 mm |
Size | 48.3*0.315*3.37;48.3*8*85.6 inch;mm |
Spacing | 0.31;8 in;in |
Spacing | 0.31 in |
Spacing | 7.874 mm |
Standard | UL 94V-0 |
Tool Size | 0.136;3.5 inch;mm |
Tool Size | 0.136 inch |
Type | Spring Loaded Screw Clamp Terminal Block |
Voltage Rating | 400 V |
Wire Size | 0.0093 inch² |
Wire Size | 6 mm² |
