TE Connectivity 1SNA105265R0300 - - Save space with compact over-all dimensions terminal block, - Flexibility: snap onto symmetrical and asymmetrical rails.
TE Connectivity

1SNA105265R0300

Alternate Item Number: 1SNA105265R0300

UPC: 88861417139

Documents & Media
Specification Sheet

Contact for Pricing

Minimum Qty: 100

Multiplier: 100

*Contact for lower quantities*

Overview

The TE Connectivity 1SNA105265R0300 terminal block offers a compact design for efficient space utilization in industrial control panels and automation systems. Its overall dimensions are optimized for tight installations, making it an ideal choice where panel real estate is at a premium. A key feature is its mounting flexibility, allowing it to snap securely onto both symmetrical (e.g., TS35) and asymmetrical (e.g., TS32) DIN rails. This versatility simplifies installation and retrofitting across various existing rail infrastructures. Manufactured by TE Connectivity, a recognized leader in connectivity solutions, this terminal block ensures reliable electrical connections for demanding industrial environments. Its robust construction, originating from Germany (DE), signifies a commitment to quality and durability. The UNSPSC code 39121410 categorizes it within electrical components, specifically terminal blocks. This product is designed for applications requiring dependable and adaptable wiring solutions, such as in machinery, power distribution, and control cabinets. The 1SNA105265R0300 provides a practical and space-efficient method for terminating wires, contributing to organized and maintainable electrical assemblies.
  • Space-saving compact overall dimensions
  • Flexible snap-on mounting for symmetrical rails
  • Flexible snap-on mounting for asymmetrical rails
  • Manufactured by TE Connectivity
  • Originating from Germany (DE)

Specifications

Mounting Type
Snap-on rail mount
Size
Compact
