TE Connectivity 1838275-3 - 5 Position Circular Connector, Cable-to-Cable, Sealable, Wire & Cable, Signal, Reverse Gender, Plastic, A Code, PA, Hermetically Sealed, M12 Connector
TE Connectivity

1838275-3

Documents & Media
BrochureFull Engineering Drawing

Contact for Pricing

Minimum Qty: 50

Multiplier: 2000

*Contact for lower quantities*

Overview

The TE Connectivity 5-Position M12 Circular Connector, SKU: 1838275-3, is engineered for reliable signal transmission in demanding industrial applications. This cable-to-cable connector features a reverse gender design and is constructed from durable Plastic (PA) material, ensuring longevity in harsh environments. Its sealable design provides crucial protection against moisture, dust, and other contaminants, making it suitable for industrial automation, control systems, and other critical infrastructure where consistent signal integrity is paramount. Drawing from TE Connectivity's extensive experience in connector technology, this M12 connector adheres to high standards for electrical and mechanical performance. While specific electrical ratings are not detailed in the provided catalog excerpts for this exact SKU, M12 connectors are commonly used for signal applications in industrial settings. The 'A' coding typically signifies standard signal assignments for M12 connectors. The reverse gender configuration offers flexibility in system design and installation. This connector is part of a broader range of TE Connectivity circular connectors, including the Triad 01 series, which emphasizes sealable designs for cable-to-cable and wire-to-panel applications, often featuring gold-plated contacts for enhanced conductivity and durability, or nickel-plated zinc die cast housings for robust panel mount solutions. The 1838275-3 specifically focuses on a plastic construction for its housing, balancing durability with weight and cost-effectiveness. Its hermetically sealed nature is a key differentiator, ensuring performance even in environments with significant ingress potential.
  • 5-Position M12 Circular Connector
  • Cable-to-Cable Connection Type
  • Hermetically Sealed for Environmental Protection
  • Reverse Gender Configuration
  • Durable Plastic (PA) Housing
  • A-Code for Standard Signal Applications
  • TE Connectivity Brand Reliability

Specifications

Amperage Rating
5 A
Color
Black
Conductor Range
22 - 20
Environmental Conditions
IP67
Number of Conductors
5
Temperature Rating
-40 - 85 °C
Type
Plug
Voltage Rating
500 VAC
