Contact for Pricing
Overview
- 3000 VA power rating for substantial industrial loads.
- Copper wound construction for enhanced durability and efficiency.
- Multi-voltage primary options: 240x480, 230x460, 220x440 VAC.
- Versatile secondary output: 120 VAC (60 Hz), 115 VAC (50/60 Hz), 110 VAC (50/60 Hz).
- Open style design for efficient cooling and simplified maintenance.
Specifications
Application | Best choice when 80% or more of the load components are electromagnetic |
Brand Name | SolaHD |
Frequency | 50/60 Hz |
Frequency Rating | 50/60 HZ |
Height | 6.25 IN |
KVA Rating | 3 |
Length | 10 IN |
Material | Copper Wound |
Mounting | Mtg Width 5.75, Mtg Depth 7.75, Slot Size .44 x .69 IN |
Mounting Type | Open Style |
Number Of Phases | 1 |
Primary Voltage | 240 480 V |
Secondary Voltage | 120 Volt Secondary 60 Hz |
Secondary Voltage | 0.12 kV |
Series | SBE |
Special Features | High Quality Silicon Steel Core, Meets or exceeds electrical requirements of NEMA, ANSI, NMTBA and JIC. |
Standard | CSA Certified: LR-14328-4, CSA C22.2 No. 66. RoHS Compliant;UL Listed: E77014, UL 506 |
Standard | UL Listed: E77014, UL 506; CSA Certified: LR-14328-4, CSA C22.2 No. 66. RoHS Compliant |
Temperature Rating | 55 DEG C Temperature Rise Under Full Load |
Temperature Rating, Maximum | 131 F |
Temperature Rating, Maximum | 55 C |
Temperature Rating, Minimum | 131 F |
Temperature Rating, Minimum | 55 C |
Type | SBE Open Style, Copper Wound |
Voltage Rating | 240/480 V primary, 120 V secondary |
Wattage | 2 KVA |
Width | 6.75 IN |
Package Dimensions (L x W x H) | 13.9 IN x 9.9 IN x 8.7 IN |
Package Dimensions (L x W x H) | 35.306 cm x 25.146 cm x 22.098 cm |
Package Weight (Imperial) | 72.550 L |
Package Weight (Metric) | 32.909 kg |
Frequently Asked Questions
What is the VA rating for the Y3000 model?
The Y3000 model has a VA rating of 3000.
What is the approximate shipping weight of the Y3000?
The approximate shipping weight for the Y3000 transformer is 74.0 lbs (33.64 kg).
Are fuse holders available for this voltage configuration?
No, fuse holders are not available for this specific voltage configuration.
Is the SBE Series RoHS compliant?
Yes, the SBE Series of industrial control transformers is RoHS Compliant.
What is the primary application of the SBE Series?
The SBE Series is best for applications where 80% or more of the load components are electromagnetic devices.
What are the primary voltage options for the Y3000 transformer?
The Y3000 transformer supports primary voltages of 240 X 480V (60 Hz), 230 X 460V (50/60 Hz), and 220 X 440V (50/60 Hz).
What is the secondary voltage of the Y3000 transformer?
The Y3000 transformer has secondary voltages of 120V (60 Hz), 115V (50/60 Hz), and 110V (50/60 Hz).
What are the dimensions of the Y3000 transformer?
The Y3000 transformer is 8.00 inches high, 9.00 inches wide, and 9.63 inches deep.
What are the mounting dimensions for the Y3000?
The Y3000 requires a mounting width of 8.00 inches and a mounting depth of 6.00 inches.
What is the slot size for mounting the Y3000?
The mounting slot size for the Y3000 transformer is .44 x .69 inches.
