Overview
- 2000 VA power rating for industrial control applications
- Copper wound construction for efficient energy transfer and durability
- Multiple primary voltage options: 240x480V, 230x460V, 220x440V
- Versatile secondary voltage outputs: 120V, 115V, 110V
- Designed for 50/60 Hz operation, suitable for various power grids
- Open-style design for easy installation and effective heat dissipation
- Manufactured in the US for assured quality and reliability
Specifications
Application | Best choice when 80% or more of the load components are electromagnetic |
Brand Name | SolaHD |
Current Rating | 8.33 A (2000 VA / 240 VAC) |
Frequency | 50/60 Hz |
Frequency Rating | 50/60 HZ |
Height | 6.25 IN |
KVA Rating | 2 |
Length | 8.75 IN |
Material | Copper |
Mounting | Mtg Width 5.75, Mtg Depth 6.38, Slot Size .44 x .69 IN |
Number Of Phases | 1 |
Primary Voltage | 240 480 V |
Secondary Voltage | 120 Volt Secondary 60 Hz |
Secondary Voltage | 0.12 kV |
Series | SBE |
Special Features | High Quality Silicon Steel Core, Meets or exceeds electrical requirements of NEMA, ANSI, NMTBA and JIC. |
Standard | UL Listed: E77014, UL 506; CSA Certified: LR-14328-4, CSA C22.2 No. 66. RoHS Compliant |
Standard | CSA Certified: LR-14328-4, CSA C22.2 No. 66. RoHS Compliant;UL Listed: E77014, UL 506 |
Temperature Rating | 55 DEG C Temperature Rise Under Full Load |
Temperature Rating, Maximum | 131 F |
Temperature Rating, Maximum | 55 C |
Temperature Rating, Minimum | 131 F |
Temperature Rating, Minimum | 55 C |
Type | SBE Open Style, Copper Wound |
Voltage Rating | 240/480 VAC, 230/460 VAC, 220/440 VAC (Primary); 120 VAC, 115 VAC, 110 VAC (Secondary) |
Wattage | 1.5 KVA |
Width | 6.75 IN |
Package Dimensions (L x W x H) | 7.6 IN x 12 IN x 7.2 IN |
Package Dimensions (L x W x H) | 19.304 cm x 30.48 cm x 18.288 cm |
Package Weight (Imperial) | 56.300 L |
Package Weight (Metric) | 25.538 kg |
Frequently Asked Questions
What is the VA rating of the Y2000 transformer?
The SolaHD Y2000 industrial control transformer has a VA rating of 2000.
What are the primary voltage options for the Y2000?
The Y2000 transformer supports primary voltages of 240 X 480V (60 Hz), 230 X 460V (50/60 Hz), and 220 X 440V (50/60 Hz).
What are the secondary voltage options for the Y2000?
The Y2000 transformer offers secondary voltages of 120V (60 Hz), 115V (50/60 Hz), and 110V (50/60 Hz).
What are the dimensions of the Y2000 transformer?
The Y2000 transformer measures 6.25 in height, 6.75 in width, and 10.00 in depth.
What is the shipping weight of the Y2000?
The approximate shipping weight for the Y2000 transformer is 55.0 lbs (25.00 kg).
What are the mounting dimensions for the Y2000?
The Y2000 requires a mounting width of 5.75 in and a mounting depth of 7.75 in. The slot size is .44 x .69 in.
What certifications does the SBE Series hold?
The SBE Series is UL Listed E77014 (Type SZO, UL 5085-1, UL 5085-2) and CSA Certified LR14328-4 (CSA C22.2 No. 66.1, No. 66.2). It is also RoHS Compliant.
Are fuse holders available for this transformer configuration?
No, fuse holders are not available for this specific voltage configuration of the SBE Series transformers.
What is the insulation system temperature rating?
The SBE Series transformers, including the Y2000, feature a 105°C insulation system.
What is the temperature rise of the SBE Series transformers?
The SBE Series transformers are designed for a 55°C temperature rise.
