Contact for Pricing
Overview
- Nominal Output Voltage: 24VDC
- Nominal Output Current: 40A
- Max. Power: 960W
- Mounting Type: DIN Rail
- Input: Three-Phase, 50/60Hz
Specifications
Amperage Rating | 40 A |
Application | ATM Machines;Heavy and Light Industrial Machinery;instrumentation;Scanners;Test and Measure Equipment;Vending Machines |
Application | Heavy and Light Industrial Machinery; Test and Measure Equipment; Scanners; instrumentation; ATM Machines; Vending Machines; |
Brand Name | SolaHD |
Frequency Rating | 50/60 HZ |
Frequency Rating, Maximum | 60 Hz |
Frequency Rating, Minimum | 50 Hz |
Fuse Rating | Internally Fused |
Mounting | DIN Rail |
Phase | Three |
Phase | 3 |
Special Features | Class I Div 2, 3-phase input, 2 year warranty |
Standard | UL Listed, Industrial Control Equipment for US and Canada: UL 508, CSA C22.2 No. 107.1; UL Recognized Component, ITE for US and Canada: UL 62368-1/CSA C22.2 No. 62368-1, UL 60950-1/CSA C22.2 No. 60950-1; CE: IEC/EN60950-1, IEC/EN62368-1 |
Standard | CE: IEC/EN60950-1, IEC/EN62368-1;UL Listed, Industrial Control Equipment for US and Canada: UL 508, CSA C22.2 No. 107.1;UL Recognized Component, ITE for US and Canada: UL 62368-1/CSA C22.2 No. 62368-1, UL 60950-1/CSA C22.2 No. 60950-1 |
Sub Brand | Sola |
Type | SVL Essential Din Rail Series |
Voltage Rating | 24 VDC |
Wattage | 960 W |
Package Dimensions (L x W x H) | 4.62 IN x 10 IN x 4.76 IN |
Package Dimensions (L x W x H) | 11.7348 cm x 25.4 cm x 12.0904 cm |
Package Weight (Imperial) | 5.7300 L |
Package Weight (Metric) | 2.5991 kg |
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
ACS380-040S-07A2-4
ACS380 AC Drive, 3-380-480V In, 3HP, 6A, Type OPEN, 1.5 overload, Integrated, HxWxD 6.69x2.76x7.52 in, Module
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
XT2NU3090BFF000XXX
C.BREAKER TMAX XT2N 125 UL/CSA FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 90 I3=450...900 A
NNC75X75WH2
The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.
Frequently Asked Questions
What is the input voltage range for the SVL-40-24-480?
The SVL-40-24-480 operates on a 3-phase input voltage range of 320-600 Vac or a 2-phase range of 360-600 Vac. The nominal AC range is 3 x 400-500 Vac.
What is the nominal output voltage and current?
The nominal output voltage is 24 Vdc, adjustable from 24-28 Vdc, with a nominal current of 40 A.
What is the maximum power output of this power supply?
The SVL-40-24-480 power supply has a maximum power output of 960 W.
What is the operating temperature range?
The operating temperature range for the SVL-40-24-480 is -25°C to +80°C.
What are the dimensions of the SVL-40-24-480 unit?
The dimensions are 4.76 in (H) x 10.00 in (W) x 4.62 in (D).
What type of housing does the SVL-40-24-480 have?
The SVL-40-24-480 features a metal housing.
Does the SVL-40-24-480 have overvoltage protection?
Yes, it has overvoltage protection at 32V ±10% in Hiccup Mode.
How does the short circuit protection work?
Short circuit protection operates in hiccup mode and is non-latching, meaning it auto-recovers when the fault is removed.
What is the warranty period for this product?
The SVL-40-24-480 comes with a 2-year warranty.
What is the efficiency of the SVL-40-24-480?
The efficiency of the SVL-40-24-480 is greater than 92%.
