STFV075-24L

The STFV Plus Series combines SolaHD Tracking filtration for low-energy noise and surge protection for high-energy transients. It continuously tracks the input AC power line.

The operating temperature range is -40 °C to +60 °C (-40 °F to +140 °F) at full load. It derates linearly to 60% at +70 °C (+158 °F).

The STFV Plus attenuates high-frequency noise to a maximum of -90 dB. This occurs in a range of 100 kHz to 50 MHz.

The STFV Plus provides IEEE C62.41 Category A and B Ringwave protection. It offers transient protection in all modes (L-N, L-G, and N-G).

The case dimensions for the STFV075-24L are 6.25 in x 4.75 in x 2.35 in (A x B x C).

The suggested minimum wire size for the STFV075-24L is 18 AWG.

The suggested fuse/circuit breaker ampacity for the STFV075-24L is 7.5 Amps, with a maximum of 9.375 Amps.

The STFV Plus Series comes with a ten-year limited warranty.

The STFV Plus Series is CSA C22.2 No. 8 certified, UL 1283 recognized, and RoHS Compliant.

The input voltage range for 240 Vac models is 0-275 Vrms. The line frequency is 50/60 Hz.
