Contact for Pricing
Overview
- IP67 rated for dust and water protection
- 2×100 W output, total 7.6 A at 24 VDC
- Double‑stacked design for compact installation
- 3.8 A per pair ensures high current capability
- Rugged construction for extreme industrial environments
Specifications
Amperage Rating | 7.6 Total (3.8 Max per pair) A |
Application | Class 2 Listed power supply for stand alone applications. Automotive, packaging and automated distribution operations. |
Brand Name | SolaHD |
Cable Size | Use UL 758 wire rated min. 24 V, VW-1/FT-1, max. 3.05 m. |
Efficiency | >87% |
Enclosure | IP66/67 Versatile Protection, UL50 Type4X |
Environmental Conditions | -25 to 70 C |
Frequency Rating | 50/60/400 HZ |
Frequency Rating, Maximum | 400 Hz |
Frequency Rating, Minimum | 50 Hz |
Fuse Rating | Internally fused; fuses not replaceable. |
Fuse Rating | fuses not replaceable.;Internally fused |
Height | 3.27 IN |
Length | 4.73 IN |
Material | Polyamid Nylon |
Mounting | Chassis Mounted Using Integral Mounting Tabs |
Number Of Receptacles | 5 |
Phase | 1 |
Phase | Single |
Receptacle Configuration | Input: 3-PIN IP67 molded plug (quick disconnect). Outputs: Four @ 4-PIN IP67 molded receptacle (2 per 100W) |
Special Features | Can be mounted in any orientation without limitation. Approved for AD and DC universal input. Five year limited warranty. |
Standard | cULus Listed, Industrial Control Equipment, E61379, ITE, E137632, UL 508, CSA C22.2 No. 107.1, UL 60950-1/CSA C22.2 No. 60950-1, 2nd Edition, CE - Low Voltage Directive, IEC/EN60950-1, 2nd Edition |
Type | IP67 SCP-X Extreme Enviornment Series |
Voltage Rating | AC Range 85 - 264 Vac Universal Input;DC Range 100-353 Vdc |
Wattage | 2 x 100 W |
Width | 7 IN |
Package Dimensions (L x W x H) | 23 IN x 20 IN x 0.9 IN |
Package Dimensions (L x W x H) | 58.42 cm x 50.8 cm x 2.286 cm |
Package Weight (Imperial) | 5.025 L |
Package Weight (Metric) | 2.279 kg |
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
ACS380-040S-07A2-4
ACS380 AC Drive, 3-380-480V In, 3HP, 6A, Type OPEN, 1.5 overload, Integrated, HxWxD 6.69x2.76x7.52 in, Module
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
XT2NU3090BFF000XXX
C.BREAKER TMAX XT2N 125 UL/CSA FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 90 I3=450...900 A
NNC75X75WH2
The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.
Frequently Asked Questions
What is the IP rating of this power supply?
The power supply has an IP67 rating, meaning it is self-sealed and resistant to corrosion, shock, and contamination.
What is the output voltage and power of the SCP-X?
These are 24 Vdc power supplies, available in single or dual 100 Watt models.
Can the power supply be mounted in any orientation?
Yes, it can be mounted in any orientation with no derating required.
Does the power supply require an external enclosure?
No, IP67 SCP-X power supplies mount directly to your machine, eliminating the need for separate enclosures.
What are the input voltage requirements for this power supply?
The power supplies operate at a universal 100-240 Vac input.
Are there grounded or isolated output options?
Yes, the power supplies are available in control output (grounded) and isolated output (ungrounded) versions.
What standards does the power supply meet?
It is Class 2 Listed under UL 1310 Standards for standalone applications.
What is the output current for dual models?
For dual models, the output current is 3.8 Amps per pair.
What are the available output configurations?
Models are available with a single 24 Vdc output or a dual 100 Watt model with four 24 Vdc outputs.
Is the isolated output suitable for DeviceNet applications?
Yes, isolated output models are ideal for DeviceNet applications that depend on advanced data exchange.
