Overview
- Multiple DC Outputs: 5V @ 6A, 12V @ 0.5A, -12V @ 0.5A
- Wide Input Voltage Range: 85-264 VAC / 120-300 VDC
- CSA Certified, UL Recognized Component for Canada and US
- CE Marked for IEC60950-1 Compliance
- Ideal for Industrial Control and Automation Applications
Specifications
Current Rating | 6 A (8 A peak), 0.5 A (0.7 A peak), -0.5 A (0.7 A peak) |
Voltage Rating | 85-264 VAC / 120-300 VDC |
Package Dimensions (L x W x H) | 5.9 IN x 4 IN x 1.6 IN |
Package Dimensions (L x W x H) | 14.986 cm x 10.16 cm x 4.064 cm |
Package Weight (Imperial) | 0.650 L |
Package Weight (Metric) | 0.295 kg |
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
ACS380-040S-07A2-4
ACS380 AC Drive, 3-380-480V In, 3HP, 6A, Type OPEN, 1.5 overload, Integrated, HxWxD 6.69x2.76x7.52 in, Module
XT2NU3090BFF000XXX
C.BREAKER TMAX XT2N 125 UL/CSA FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMA R 90 I3=450...900 A
NNC75X75WH2
The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
Frequently Asked Questions
What is the input voltage range for GLT43?
The GLT43 operates with a universal AC input voltage range of 85-264 Vac and a DC input range of 120-300 Vdc.
What are the output specifications for the GLT43 model?
The GLT43 provides outputs of 5 V @ 4 A, 15 V @ 2 A, and -15 V @ 0.5 A. These ratings increase with 30 CFM of air.
What is the operating temperature range for GLT43?
The GLT43 operates from 0°C to 50°C ambient at full power. It can operate up to 70°C with a 2.5% derating per degree above 50°C.
Does the GLT43 have overvoltage protection?
Yes, the GLT43 features overvoltage protection. For the 5 V output, it is 5.7 to 6.7 Vdc, and for other outputs, it is 10% to 25% above nominal.
What is the warranty period for GLT43 power supplies?
The GLT43 comes with a two-year limited warranty.
Does the GLT43 include EMI filtering?
Yes, all GL series models, including the GLT43, feature built-in EMI filtering. It meets FCC Class B, CISPR 22 Class B, and EN55022 Class B standards.
How does the remote sense feature work on GLT43?
Remote sense compensates for a 0.5 V lead drop minimum. The unit will operate even if remote sense is not connected and is protected against reverse connections.
What is the power rating of GLT43 with a cover?
When a cover/enclosure option is used, the GLT43 has a power rating of 25 watts, or 40 watts with 30 CFM of air.
What is the power rating of GLT43 without a cover?
Without a cover option, the GLT43 has a power rating of 40 watts, or 55 watts with 30 CFM of air.
Which mating connectors are compatible with GLT43?
The GLT43 uses mating connector type 3B. The kit includes Molex 09-50-8031 (AC Input), 09-50-8061 (DC Outputs), and 22-01-2025 (Remote Sense).
