Contact for Pricing
Overview
- 2000VA power rating for industrial applications
- 130°C insulation system for enhanced durability and safety
- UL (Canada and US), CE, IEC, and ANSI certified for global compliance
- Wide input voltage range: 240/415/480, 230/400/460, 220/380/440V AC
- Flexible output voltage options: 120/240, 115/230, 110/220V AC
- 50/60 Hz frequency compatibility
Specifications
Application | Industrial Automation and Control Equipment Power PLCs, Machine Tools, Robotics, Semiconductor Fabrication Equipment |
Brand Name | SolaHD |
Current Rating | 8.33 A (2000VA / 240V) |
Enclosure | IP20 |
Frequency | 50/60 Hz |
Frequency Rating | 50/60 HZ |
Height | 5.63 IN |
Insulation Class | 130 DEG |
KVA Rating | 2 |
Length | 6.75 IN |
Material | Electrical Steel, Copper Windings |
Mounting | Mounting Feet |
Number Of Phases | 1 |
Power Factor | 50 PCT |
Primary Voltage | 240/415/480 V |
Secondary Voltage | 120/240 V |
Series | CE2000 |
Size | 2000 VA |
Special Features | IP20 touch-proof terminals, Copper windings, Epoxy encapsulated for cooler operation and increased reliability, 50/60 Hz frequency, 80 DEGC/176 DEGF Rise, 130 DEGC/266 DEGF insulation system for harsh, heavy duty applications, Meets or exceeds electrical requirements of NEMA, ANSI and IEC |
Standard | cULus Listed: E77014, UL 506, CSA C22.2 No.66 IEC 61558-1, Iec 61558-2-2, RoHS Compliant |
Type | ICE International Series: 750-2,000 VA. |
Voltage Rating | Input: 240/415/480V, 230/400/460V, 220/380/440V AC; Output: 120/240V, 115/230V, 110/220V AC |
Wattage | 1500 VA |
Width | 6.38 IN |
Package Dimensions (L x W x H) | 8 IN x 9 IN x 9.5 IN |
Package Dimensions (L x W x H) | 20.32 cm x 22.86 cm x 24.13 cm |
Package Weight (Imperial) | 45.000 L |
Package Weight (Metric) | 20.412 kg |
Frequently Asked Questions
What is the continuous power rating of the CE2000TH?
The CE2000TH transformer has a continuous power rating of 2000 VA.
What is the instantaneous power rating of the CE2000TH?
The CE2000TH transformer has an instantaneous power rating of 5500 VA.
What are the primary voltage options for the CE2000TH?
The CE2000TH supports primary voltages of 240/415/480V (60Hz), 230/400/460V (50/60Hz), and 220/380/440V (50/60Hz).
What are the secondary voltage options for the CE2000TH?
The CE2000TH offers secondary voltages of 120/240V (60Hz), 115/230V (50/60Hz), and 110/220V (50/60Hz).
What operating frequencies does the CE2000TH support?
The CE2000TH transformer operates at both 50 Hz and 60 Hz frequencies.
What are the physical dimensions of the CE2000TH transformer?
The CE2000TH is 5.63 in high, 6.38 in wide, and 7.75 in deep.
What are the mounting dimensions for the CE2000TH?
The mounting width is 5.31 in, and the mounting depth is 6.00 in. The slot size is .31 x .69 in.
What certifications does the CE2000TH transformer hold?
The CE2000TH is CE marked, cULus approved, UL 5085-1/2, CSA C22.2 No. 66.1/2, IEC 61558-1/2-2, and RoHS Compliant.
What are the secondary fuse recommendations for the CE2000TH?
For 115 Vac output, a 16 A fuse is recommended, and for 230 Vac output, an 8 A fuse is recommended.
Where can I find primary fusing recommendations?
Primary fusing recommendations should be determined by consulting local electrical codes.
