Contact for Pricing
Minimum Qty: 200
Multiplier: 200
*Contact for lower quantities*
Overview
- Designed for 4 AWG copper wire with a 1/4" stud size.
- Non-insulated tubular design for secure, high-vibration applications.
- Brazed seam prevents barrel splitting during crimping.
- Internal barrel serrations for optimal wire contact and tensile strength.
- UL and CSA rated up to 2000 V per UL 486A/B.
Specifications
Amperage Rating | NA A |
Angle* | Straight |
Barrel Type* | Short |
Cable Size | 4 AWG |
Color | Gray |
Connection | Beveled |
Insulation | Non-Insulated |
Material | Tin-plated Copper |
Mounting | 1/2 In. |
Number Of Holes | NA |
Special Features | Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V |
Standard | UL Listed to 486A-486B File #E52164, CSA certified C22.2 No. 65-13 |
Stud Size | 1/4 In. |
Type | Tubular Ring Compression Lug |
Voltage Rating | NA V |
Package Dimensions (L x W x H) | 5.75 IN x 3.4 IN x 3.35 IN |
Package Weight (Imperial) | 3.92 lbs |
OD581
Mechanical Crimp Tool with 5/8 Inch Nose Die APPLICATIONS: Designed for use with wide range and H-Tap connectors. It has fiberglass handles and comes with "O" and "D" Nose Dies. It has an output of 4.5 tons.
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
CD7
U-Type Compression Die - Black 2/0 AWG Copper U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
E6-PS-D
Non-Insulated Parallel Splice Connector For Wire Range 6 For Circular Mil Range 20,800-33,100 Length .5 Diameter .365,Metallic
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
How to Install Copper Compression Connectors
This guide provides step-by-step instructions for properly installing copper compression connectors using the appropriate tools and techniques.
Estimated time: 30m
Tools needed:
Crimping tool, Wire strippers, Multimeter
Supplies needed:
Copper compression connectors, Wire
- Prepare the wire
Strip the insulation from the end of the wire to a length specified for the connector size, typically 7/16" for #8 AWG wire.
- Insert the connector
Insert the stripped end of the wire into the copper compression connector until it reaches the bottom of the barrel.
- Crimp the connector
Using the appropriate crimping tool, crimp the connector between the color bands or knurl markings, starting near the tongue end and moving towards the wire end.
- Inspect the connection
After crimping, inspect the connector for sharp edges, flash, or burrs and remove any imperfections to ensure a clean connection.
- Test the connection
Use a multimeter to verify the integrity of the connection by checking for continuity and ensuring there are no shorts.
