Panduit PV12-14HDR-L - Ring Terminal, 16 12 AWG, 1/4" stud size, heavy duty, vinyl insulated, funnel entry, standard package.
Panduit

PV12-14HDR-L

UPC: 074983802586

Documents & Media
Technical DrawingFull Engineering Drawing

Contact for Pricing

Minimum Qty: 50

Multiplier: 50

*Contact for lower quantities*

Overview

The Panduit PV12-14HDR-L is a heavy-duty, vinyl-insulated ring terminal designed for reliable electrical connections. Engineered for wire sizes ranging from 16 to 12 AWG, this terminal features a 1/4" stud size, ensuring compatibility with standard electrical hardware. The funnel entry design facilitates easier wire insertion, reducing installation time and minimizing the risk of wire strand damage during crimping. This feature is crucial in high-vibration or demanding environments where a secure and efficient connection is paramount. The PV series ring terminals from Panduit are constructed with high-quality vinyl insulation, providing excellent electrical isolation and protection against environmental factors. The heavy-duty construction signifies its suitability for applications requiring robust performance and durability. The standard package quantity ensures that you have an adequate supply for your project needs. Key specifications include: * **Manufacturer:** Panduit * **SKU:** PV12-14HDR-L * **Wire Gauge:** 16-12 AWG * **Stud Size:** 1/4" * **Insulation Material:** Vinyl * **Terminal Type:** Ring Terminal * **Entry Type:** Funnel Entry * **Series:** PV * **Country of Origin:** US This ring terminal is ideal for use in industrial control panels, automotive applications, power distribution systems, and any scenario where secure and lasting electrical connections are essential. The combination of durable materials, user-friendly design, and adherence to quality manufacturing standards makes the Panduit PV12-14HDR-L a dependable choice for electrical professionals. Its robust build and specific design features contribute to reduced maintenance and improved operational safety.
  • Heavy-duty vinyl insulated ring terminal for 16-12 AWG wire
  • 1/4" stud size for standard electrical connections
  • Funnel entry design for easy wire insertion and reduced damage
  • Durable vinyl insulation provides electrical protection
  • Panduit PV series for reliable performance in industrial applications

Specifications

Color
Yellow
Connection
Funnel Entry
Enclosure
Ring shape
Finish
Tin-Plated
Insulation
Vinyl
Material
Copper
Mounting
9/32 In.
Size
1/4"
Standard
UL Listed 587H E52164, CSA Certified LR31212
Temperature Rating
221 Degrees Fahrenheit (105 Degrees Celsius)
Type
Ring Terminal
Voltage Rating
600 V
Wire Size
#12 AWG
Package Dimensions (L x W x H)
10.05 IN x 4.2 IN x 4.35 IN
Package Weight (Imperial)
3.75 lbs
